Vishay Bridge Rectifier 1000 V 450 A 4-Pin Single PB5010-E3/45

Vishay PB5010-E3/45 Bridge Rectifier is designed for demanding industrial and electronic applications requiring reliable AC/DC rectification. It features a 1000 V peak reverse repetitive voltage capability and a peak surge current of 450 A, making it suitable for high current density environments.

This 4-pin single bridge rectifier package supports through-hole mounting, facilitating robust integration on printed circuit boards. The device operates efficiently with a low forward voltage of 1.1 V and sustains continuous forward current of 45 A, while maintaining stable performance at temperatures up to 150°C. Its compact dimensions (30.3 mm length x 20.3 mm height x 5.1 mm width) contribute to space-saving designs.

Primarily used in switching power supplies, home appliances, and white goods, this rectifier delivers superior thermal conductivity ensuring durability and consistent performance. It does not conform to automotive standards, and the country of origin is China.

Through-hole mount type for reliable PCB integration. 4-pin single configuration suitable for general purpose AC/DC rectification. Maximum operating temperature up to 150°C ensures thermal stability. Low forward voltage drop of 1.1 V for efficient power conversion.

Compact dimensions measuring 30.3 mm length by 20.3 mm height and 5.1 mm width. Supports a forward current of 45 A and withstands peak reverse current of 500 μA. Package type PB series with no automotive standard certification.

Designed for use in switching power supplies, home appliances, and white goods.

Suitable for industrial, commercial, and manufacturing applications involving power conversion and electrical rectification, the Vishay PB5010-E3/45 Bridge Rectifier offers reliable and efficient operation.
