Nexperia Schmitt Trigger Input CMOS Inverter 6 Elements 14-Pin SO-8 4.5-5.5 V 74HCT14D,653

Nexperia 74HCT14D,653 CMOS Inverter IC provides six independent Schmitt Trigger input inverters in a 14-pin SO-8 surface mount package. This component is designed for high-speed CMOS logic applications, operating at supply voltages ranging from 4.5 V to 5.5 V. The device operates reliably over a wide temperature range from -40°C to 125°C, making it suitable for industrial and commercial electronic circuits requiring noise immunity and precise signal conditioning.

This inverter belongs to the 74HCT logic family and is compatible with TTL inputs and CMOS outputs, allowing for flexible interfacing in mixed-logic environments. The Schmitt Trigger input enhances signal integrity by providing hysteresis and noise rejection, particularly useful in signal conditioning and waveform shaping applications.

The device has a maximum propagation delay of 51 ns at a capacitive load, ensuring fast switching speeds for timing-critical applications. It supports maximum output currents of ±4 mA and is packaged in a compact 14-pin SO-8 format, ideal for surface mount technology (SMT) PCBs.

Nexperia's 74HCT14D,653 inverter IC is widely used in industrial electronics, automation controllers, communication equipment, and other applications that require robust logic signal processing with enhanced noise immunity and compact board design.

Six Schmitt Trigger input inverters per chip enhance signal stability. Wide operating temperature range from -40°C to 125°C supports harsh environments. TTL compatible inputs with CMOS outputs facilitate interfacing. Compact SO-8 surface mount package enables space-saving PCB layouts.

Fast switching speeds with 51 ns propagation delay support high-frequency circuits. Low power consumption embedded in 74HCT logic family architecture. Maximum supply voltage of 5.5 V ensures voltage tolerance in circuits.

Dimensions tailored for SMT applications: 14 pins, 8.75 mm length, 4 mm width, and 1.45 mm height.

This high-performance inverter component is suitable for electronics manufacturing, industrial automation systems, communication devices, and electronic design prototyping. Find more semiconductor and logic IC components like the Nexperia 74HCT14D,653 in the EnvMart catalog for your engineering and production needs.
