Murata Power Solutions 1.5 mH Leaded Inductor Radial Mount, 1.7A Max DC Current, 374mΩ DC Resistance, Max SRF 700 1415517C

Murata Power Solutions 1415517C is a high-current leaded inductor with a radial mount type, featuring a 1.5 mH inductance and capable of handling a maximum DC current of 1.7 A. Designed specifically for power line applications such as switching regulators, filters, and suppression circuits, this inductor delivers reliable performance with a maximum self-resonant frequency of 700 kHz and a minimum quality factor of 28.

This component is constructed from high saturation flux density material, enhancing its capacity for use in high current applications. It is suitable for PCB or chassis mounting using a non-magnetic fastener via its central fixing hole. The inductor features solder termination with easy-strip pre-tinned enamelled copper leads, each 10 mm in length, facilitating straightforward installation.

With an operating temperature range of -40°C to +85°C and an inductance tolerance of ±10%, this inductor meets stringent industry requirements. Its physical dimensions include a diameter of 29.8 mm, height of 23.3 mm, length of 32.8 mm, depth of 31.3 mm, and a lead pitch of 28.8 mm, making it compatible with various designs.

High current radial inductor designed for power line applications. Maximum self-resonant frequency 700 kHz for high-frequency operation. Lead diameter 0.75 mm and pitch 28.8 mm for PCB mounting. Constructed from high saturation flux density material.

Operating temperature range from -40°C to +85°C. Easy-strip pre-tinned enamelled copper leads, 10 mm length. RoHS compliant with ±10% inductance tolerance. Physical dimensions: 29.8 mm diameter, 23.3 mm height, 32.8 mm length, 31.3 mm depth.

This leaded inductor is ideal for use in industrial electronics, power supply systems, manufacturing equipment, and HVAC control circuits where reliable current handling and stable inductance are critical. The product is manufactured in China and meets RoHS standards for environmental compliance.
