Panasonic Hinge Lever Micro Switch, Solder Terminal, 100mA, 250 V AC, 30 V DC, SPCO AVL322561-A
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Model | AVL322561-A |
| Series | AVL |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPCO |
| Actuator Type | Hinge Lever |
| Minimum Operating Temperature | -25°C |
| Terminal type | Solder |
| Standards/Approvals | VDE, UL, SEMKO, RoHS, CSA |
| Contact DC Voltage | 30V dc |
| Switch Contact Current | 100mA |
| Operating Force | 0.54N |
| Mechanical Life | 10Operations |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Subminiature |
| Panasonic Hinge Lever Microswitch, Solder Terminal, 100 mA @ 30 V dc, SPDTBrand | Panasonic |
Key Features
- Equipped with a hinge lever actuator for precise switching action.
- Solder type terminals ensure secure electrical connections.
- Single pole changeover (SPCO) contact configuration for versatile usage.
- Operating current capacity of 100mA suitable for low power applications.
- Wide operating temperature range from -25°C to 85°C for diverse environments.
- Contact voltage ratings of 250 V AC and 30 V DC for reliable electrical performance.
- Subminiature switch type designed for compact applications.
- Low operating force of 0.54 N ensures sensitivity and responsiveness.
Product Description
Panasonic AVL322561-A is a high precision subminiature micro switch featuring a hinge lever actuator and solder terminal connections. This switch supports a switch contact current of 100mA and contact voltages of 250 V AC and 30 V DC, making it suitable for a variety of low power switching applications.
The device is engineered for long-term reliability with a mechanical life of 10 million operations and a robust contact design using AgNi alloy or gold clad contacts for enhanced electrical endurance. The operating force required is low at 0.54 N, offering precise and sensitive activation.
This micro switch operates effectively over a temperature range of -25°C to 85°C, suitable for industrial environments including communication equipment, vending machines, security systems, data systems, and medical devices.
The solder terminal type ensures durable and secure connections, while the single pole changeover (SPCO) contact configuration provides versatile switching options. Panasonic AVL322561-A meets multiple international standards including VDE, UL, SEMKO, RoHS, and CSA, ensuring safety and compliance in industrial applications.
Equipped with a hinge lever actuator for precise switching action. Solder terminal type for reliable electrical connections. SPCO contact configuration for versatile switching. Supports 100mA current with 250 V AC and 30 V DC ratings.
Wide operating temperature range of -25°C to 85°C. Long mechanical life of up to 10 million operations. Certified to multiple international standards. Ideal for industrial, communication, medical, and security systems. Durable AgNi alloy or gold clad contacts for high reliability.
Compact subminiature design for space saving installations.
This Micro Switch is a reliable choice for diverse industrial uses including automation, control panels, HVAC equipment, telecommunications, and instrumentation systems. It offers exceptional performance, durability, and compliance making it suitable for high-precision switching tasks. Explore more industrial switches and components at EnvMart for comprehensive automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this micro switch is 85°C.
It features a single pole changeover (SPCO) contact configuration, allowing for versatile switching options.
This model supports an operating current capacity of 100mA, making it suitable for low power applications.
The contact voltage ratings are 250 V AC and 30 V DC, ensuring reliable electrical performance.
It uses a hinge lever actuator for precise switching action.
The mechanical life of this switch is rated at 10 million operations, ensuring long-term reliability.
The minimum operating temperature for this micro switch is -25°C.
The operating force required for activation is low at 0.54 N, providing sensitivity and responsiveness.
It features solder type terminals, ensuring secure and durable electrical connections.
This micro switch meets multiple international standards including VDE, UL, SEMKO, RoHS, and CSA.
This model is classified as a subminiature switch type, designed for compact applications.
