Nexperia Resistor-Equipped Transistor PNP 100 mA, 50 V, 3-Pin DFN1412D-3 PDTA124XQC-QZ

Nexperia PDTA124XQC-QZ resistor-equipped transistor is a PNP bipolar transistor designed for efficient switching and control applications, offering a collector current of 100 mA and maximum voltage of 50 V. Its ultra-small DFN1412D-3 package with plastic body and side-wettable flanks make it ideal for automated surface-mount assembly and optical inspection.

This transistor integrates built-in resistors, simplifying circuit design by reducing the need for additional components and allowing lower assembly complexity. The low package height of 0.5 mm facilitates compact PCB designs. It operates reliably over a wide temperature range from -55°C up to 150°C, and complies with the automotive AEC-Q101 standard, ensuring suitability for automotive and industrial electronic applications.

Typical applications include controlling IC inputs, switching moderate loads, and use in digital circuits where cost and space savings are critical. The transistor's PNP polarity and three-pin configuration support easy implementation in various circuit topologies.

Key benefits include reduced component count due to integrated resistors, cost saving as an alternative to BC857 transistors, and enhanced manufacturing yields from automated optical inspection capability.

Maximum DC collector current of 100 mA. Collector emitter voltage rating of 50 V. Built-in resistors to simplify designs. Compact DFN1412D-3 surface-mount package. AEC-Q101 automotive standard compliant. Wide temperature operation from -55°C to 150°C.

Side-wettable flanks for solder joint inspection. PNP transistor configuration. Suitable for switching and digital applications. Low package height of 0.5 mm.

Used extensively in industrial, automotive, and digital semiconductor applications, this transistor offers reliable performance and manufacturing efficiency gains. Explore similar Bipolar Transistors and discrete semiconductor components for your design needs on EnvMart.
