Panasonic Shielded Wirewound Surface Mount Inductor Metal Composite Core 22 μH ±20% 2.7A ETQP3M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 3mm |
| Length | 6.4mm |
| Model | ETQP3M |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | ETQP3M |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 22μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 2.7A |
| Pin Count | 2 |
| Maximum DC Resistance | 140.8mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- The inductor features a metal composite core for high heat resistance and reliability.
- It has a shielded construction to reduce electromagnetic interference.
- Supports operation temperatures from -55°C up to 155°C for high thermal stability.
- Designed for surface mount applications with a compact 6.4 mm length, 3 mm height, and 6 mm depth.
- Includes tape and reel packaging suitable for automated assembly processes.
- Provides low audible noise and vibration resistance with wirewound construction.
- Meets Automotive Standard AEC-Q200 ensuring quality and durability.
- Maximum DC resistance is 140.8 mΩ ensuring efficient current handling.
Product Description
Panasonic ETQP3M Shielded Wirewound Surface Mount Inductor is engineered with a metal composite core that provides excellent heat resistance and high reliability. Its robust shielded construction minimizes electromagnetic interference, making it ideal for demanding electronics environments.
This inductor operates efficiently within a temperature range of -55°C to 155°C, ensuring stable performance even under high thermal stress. Featuring a wirewound construction on a ferrous alloy magnetic material, it offers excellent inductance stability and low audible noise during operation.
The component is designed specifically for surface mount applications with dimensions 6.4 mm in length, 3 mm in height, and 6 mm in depth. Packaged in tape and reel format, it facilitates automated assembly and production efficiency.
Robust electrical characteristics include a 22 μH inductance with a tolerance of ±20%, a maximum DC current of 2.7 A, and a maximum DC resistance of 140.8 mΩ. The inductor supports a maximum self-resonant frequency of 100 kHz, catering to various high-frequency circuit requirements.
This inductor complies with the stringent Automotive Standard AEC-Q200, ensuring its suitability for automotive and other reliability-critical industrial applications. It is a molded component designed to withstand vibrations and harsh operating conditions.
The inductor features a metal composite core for enhanced heat and vibration resistance. Shielded design minimizes electromagnetic interference in sensitive circuits. Wide operating temperature range from -55°C to 155°C for versatile use.
Surface mount form factor with compact dimensions supports automated assembly. Tape and reel packaging improves production efficiency. Wirewound construction ensures high inductance stability and low noise. Meets Automotive Standard AEC-Q200 for reliability in automotive environments.
Low DC resistance of 140.8 mΩ enhances current efficiency. Operates reliably up to 100 kHz self-resonant frequency.
This Panasonic ETQP3M inductor is widely used in industrial, automotive, electronics manufacturing, power supply filtering, and noise suppression applications requiring high reliability and thermal stability. Explore more Surface Mount Inductors and similar components in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 22 μH with a tolerance of ±20%.
It can handle a maximum DC current of 2.7 A.
The dimensions are 6.4 mm in length, 3 mm in height, and 6 mm in depth.
The maximum operating temperature is 155°C.
The minimum operating temperature is -55°C.
The maximum DC resistance is 140.8 mΩ.
It features a metal composite core, which provides high heat resistance and reliability.
It is packaged in tape and reel format, suitable for automated assembly processes.
The maximum self-resonant frequency is 100 kHz.
This model complies with the Automotive Standard AEC-Q200.
It has a wirewound construction, which ensures high inductance stability and low audible noise.
It is suitable for industrial, automotive, electronics manufacturing, power supply filtering, and noise suppression applications.
