Nexperia High Voltage NPN Transistor 50 mA 250 V 3-Pin Surface Mount SOT-23 BF822,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia High Voltage NPN Transistor 50 mA 250 V 3-Pin Surface Mount SOT-23 BF822,215

Name: Nexperia High Voltage NPN Transistor 50 mA 250 V 3-Pin Surface Mount SOT-23 BF822,215
Brand: Nexperia
SKU: 303092
Price: 0.13 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	BF822,215
Width	2.5mm
Mount Type	Surface
Series	BF822
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	3
Maximum Collector Emitter Voltage Vceo	250V
Minimum DC Current Gain hFE	50
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	5V
Maximum Collector Base Voltage VCBO	250V
Maximum Power Dissipation Pd	250mW
Maximum DC Collector Current Idc	50mA
Transistor Configuration	Single
Maximum Transition Frequency ft	60MHz
onsemi Transistor, 500 mA NPN, 300 V, 3-Pin SOT-23Brand	onsemi

Key Features

Supports a maximum power dissipation of 250 mW.
Minimum DC current gain (hFE) of 50 ensures good amplification.
Operating temperature range from -65°C to 150°C for reliability.
Ideal for high voltage switching and amplification applications.
RoHS compliant ensuring environmental safety.
Transistor configuration is single NPN type for discrete semiconductor use.
Maximum transition frequency of 60 MHz supports moderate speed applications.
Surface mount SOT-23 package facilitates easy PCB assembly.

Product Description

Nexperia BF822,215 is a high voltage NPN bipolar transistor designed for electronic applications requiring up to 50 mA continuous collector current and voltage ratings up to 250 V.

This transistor comes in a compact 3-pin SOT-23 surface mount package, measuring 3 mm in length, 2.5 mm in width, and 1.1 mm in height, making it suitable for space-constrained PCB designs.

The device features a minimum DC current gain (hFE) of 50, allowing efficient amplification and switching performance with a maximum power dissipation capability of 250 mW.

Designed to operate reliably over a wide temperature range from -65°C to 150°C, this transistor is applicable in industrial, automotive, consumer electronics, and power supply circuits.

Its maximum transition frequency of 60 MHz enables usage in moderate frequency amplification circuits, while its high collector-emitter voltage rating of 250 V supports high voltage switching.

Being RoHS compliant, it meets environmental standards for reduced hazardous substances. Applications include signal amplification, switching, and control in power regulation, instrumentation, and general purpose electronic circuits.

Compatible with surface mount technology assembly and available in standard SOT-23 3-pin package, the BF822,215 transistor from Nexperia is a reliable choice for modern electronic designs.

Explore the full range of bipolar transistors at EnvMart for your electronic component needs. Supports a maximum power dissipation of 250 mW. Minimum DC current gain (hFE) of 50 ensures good amplification. Operating temperature range from -65°C to 150°C for reliability.

Compact dimensions: 3 mm length, 2.5 mm width, and 1.1 mm height. Ideal for high voltage switching and amplification applications. RoHS compliant ensuring environmental safety. Transistor configuration is single NPN type for discrete semiconductor use.

Maximum transition frequency of 60 MHz supports moderate speed applications. Surface mount SOT-23 package facilitates easy PCB assembly. Browse the EnvMart selection for similar semiconductors and Bipolar Transistors.
