Nexperia Resistor-Equipped NPN Transistor 100 mA 50 V 3-Pin DFN1412D-3 PDTC114YQC-QZ
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTC114YQC-QZ |
| Mount Type | Surface |
| Series | PDTC114Y |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1412D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | 50V |
| Minimum DC Current Gain hFE | 100 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 6V |
| Maximum Collector Base Voltage VCBO | 50V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | 100mA |
| Transistor Configuration | NPN |
| Maximum Transition Frequency ft | 230MHz |
Key Features
- Incorporates built-in resistors to simplify circuit design and reduce component count.
- Compact DFN1412D-3 surface mount package with side-wettable flanks and a low height of 0.5 mm.
- Features a maximum DC collector current of 100 mA and a maximum collector-emitter voltage of 50 V.
- High transition frequency of 230 MHz suitable for fast switching applications.
- Wide operating temperature range from -55°C to +150°C for reliability in harsh environments.
- Qualified to automotive standard AEC-Q101 ensuring robustness and quality.
- Cost-effective alternative to BC857 series transistors for input control and load switching.
- Compatible with automatic optical inspection (AOI) for efficient manufacturing.
Product Description
The Nexperia PDTC114YQC-QZ is a resistor-equipped NPN transistor housed in an ultra-small, leadless DFN1412D-3 package (SOT8009), designed for compact and efficient circuit integration. It supports a maximum DC collector current of 100 mA and withstands collector-emitter voltages up to 50 V, making it ideal for switching and digital control applications where space and component count reduction are critical.
This transistor features built-in resistors, which simplify circuit design and reduce the overall component count, leading to lower manufacturing costs and improved assembly efficiency. The package includes side-wettable flanks, enhancing solder joint quality and enabling compatibility with automatic optical inspection (AOI) processes.
With a high transition frequency of 230 MHz, the PDTC114YQC-QZ supports high-speed switching applications in industrial, automotive, and commercial electronics. It has a wide operating temperature range from -55°C to 150°C, ensuring robust performance in harsh environments.
Qualified to the automotive AEC-Q101 standard, this transistor meets stringent automotive reliability demands, making it suitable for automotive electronic systems as well as general industrial electronics. It is a cost-saving alternative to the BC857 series transistors, widely used for controlling IC inputs and switching loads.
Incorporates built-in resistors to simplify circuit design and reduce component count. Compact low-profile surface-mount DFN1412D-3 package with side-wettable flanks. 100 mA maximum DC collector current capability. Maximum collector-emitter voltage of 50 V.
High transition frequency of 230 MHz for fast digital switching. Wide temperature operation from -55°C to 150°C. Automotive standard AEC-Q101 qualified for automotive applications. Cost-effective, space-saving solution for digital input control and load switching.
This resistor-equipped transistor is suitable for electronics manufacturing, automotive systems, industrial control, and digital signal switching applications. Its small size and integrated resistors reduce the PCB footprint and assembly complexity, aligning well with modern high-density circuit designs. Explore more Nexperia Bipolar Transistors and related semiconductor components at EnvMart for comprehensive electronic solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum DC collector current for this model is 100 mA.
It can withstand a maximum collector-emitter voltage of 50 V.
This transistor features a maximum transition frequency of 230 MHz, suitable for fast switching applications.
The operating temperature range is from -55°C to 150°C, ensuring reliability in harsh environments.
It comes in a compact DFN1412D-3 surface mount package with side-wettable flanks.
Yes, it is qualified to the automotive standard AEC-Q101, ensuring robustness and quality for automotive systems.
This transistor has a pin count of 3.
The minimum DC current gain (hFE) is 100.
The maximum emitter-base voltage (VEBO) is 6 V, and the maximum collector-base voltage (VCBO) is 50 V.
It is suitable for electronics manufacturing, automotive systems, industrial control, and digital signal switching applications.
The built-in resistors simplify circuit design and reduce the overall component count, leading to lower manufacturing costs and improved assembly efficiency.
It complies with RoHS standards, ensuring it meets environmental regulations.
