Nexperia Schmitt Trigger Inverter Logic IC CMOS 0.8 V to 3.6 V Supply Voltage 74AUP1G14GX4-Q100Z

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Schmitt Trigger Inverter Logic IC CMOS 0.8 V to 3.6 V Supply Voltage 74AUP1G14GX4-Q100Z

Name: Nexperia Schmitt Trigger Inverter Logic IC CMOS 0.8 V to 3.6 V Supply Voltage 74AUP1G14GX4-Q100Z
Brand: Nexperia
SKU: 299645
Price: 0.2 USD
Availability: InStock



Category Inverters ICs Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	350μm
Length	650μm
Model	74AUP1G14GX4-Q100Z
Width	650μm
Mount Type	Surface
Series	74AUP1G14-Q100
Input Type	Schmitt Trigger
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS, JEDEC
Number of Elements per Chip	3
Maximum Supply Voltage	3.6V
Logic Family	CMOS
Logic Function	Inverter
Minimum Supply Voltage	800mV
Maximum Propagation Delay Time @ CL	4ns

Key Features

Features Schmitt trigger input for enhanced noise immunity.
Low static power consumption with typical ICC of 0.9 μA maximum.
Wide operating temperature range from -55°C to 125°C.
Surface mount package with dimensions of 650μm length, 650μm width, and 350μm height.
Maximum propagation delay time of 4 nanoseconds at configured load.
Input overvoltage tolerant up to 3.6 V.
Complies with RoHS and JEDEC standards.
Latch-up performance exceeds 100 mA according to JESD 78 Class II.

Product Description

Nexperia 74AUP1G14GX4-Q100Z is a Schmitt Trigger Inverter logic IC belonging to the CMOS family designed for low power dissipation and high noise immunity. This device operates over a wide supply voltage range from 0.8 V up to 3.6 V, suitable for various electronic and semiconductor applications.

It contains 3 inverter elements per chip with Schmitt trigger inputs, enabling improved signal stability and filtering of noisy input signals. The maximum propagation delay time is 4 nanoseconds, facilitating fast switching performance.

The surface mount package measures 650 μm in length, 650 μm in width, and 350 μm in height, making it suitable for compact PCB layouts. These features, in combination with compliance to RoHS and JEDEC standards, ensure environmentally friendly and reliable performance.

The device is also overvoltage tolerant up to 3.6 V and includes IOFF circuitry to provide a partial power-down mode operation, preventing potentially damaging backflow current when powered down.

Typical applications include wave and pulse shaper circuits, astable multivibrators, monostable multivibrators, and other industrial electronic systems where fast and low-power inverter functionality is required.

Features Schmitt trigger input for enhanced noise immunity. Low static power consumption with typical ICC of 0.9 μA maximum. Wide operating temperature range from -55°C to 125°C. Surface mount package with compact dimensions.

Maximum propagation delay time of 4 nanoseconds. Input overvoltage tolerance to 3.6 V. Emits low noise overshoot and undershoot less than 10% of VCC. Meets RoHS and JEDEC compliance. Latch-up immunity exceeding 100 mA per JESD 78 Class II.

IOFF circuitry enables partial power down operation. This logic IC is designed for industrial, electronic, and semiconductor manufacturing applications where power efficiency and reliable switching are critical. Explore more advanced inverter ICs and logic components in EnvMart's Electronics & Electricals category for your specialized projects and industrial requirements.
