Microchip 1700 V 10 A Schottky Barrier Schottky Diode Through Hole TO-247 MSC010SDA170B

Name: Microchip 1700 V 10 A Schottky Barrier Schottky Diode Through Hole TO-247 MSC010SDA170B
Brand: Microchip
SKU: 298087
Price: 11.72 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Model	MSC010SDA170B
Mount Type	Through Hole
Series	MSC0
Maximum Operating Temperature	175°C
Package Type	TO-247
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Maximum Continuous Forward Current If	10A
Peak Reverse Repetitive Voltage Vrrm	1700V
Rectifier Type	Schottky
Peak Non-Repetitive Forward Surge Current Ifsm	75A
Maximum Forward Voltage Vf	1.8V

Key Features

The diode uses through-hole mount type suitable for robust installations.
Maximum continuous forward current is rated at 10 amperes for sustained operation.
Peak reverse repetitive voltage reaches 1700 volts ensuring high voltage blocking capability.
Low forward voltage drop of 1.8 volts reduces power losses during conduction.
Operating temperature ranges from -55°C to 175°C for versatile thermal environments.
Peak non-repetitive forward surge current is 75 amperes enabling transient load resilience.
Complies with RoHS standards ensuring environmental safety and lead-free manufacturing.
Designed with zero recovery silicon carbide technology enabling high switching frequency performance.

Product Description

The Microchip MSC010SDA170B is a high-performance Schottky Barrier Schottky diode designed to operate at a maximum reverse voltage of 1700 V and forward current of 10 A. It is housed in a TO-247 package format with a through-hole mount type, ideal for power electronics applications requiring robust and reliable components.

This diode features zero recovery silicon carbide technology, delivering exceptionally fast switching suitable for power parallel diode applications and other high-frequency circuits. Its low forward voltage of 1.8 V helps minimize conduction losses, improving overall efficiency in power conversion and rectification tasks.

Operating temperature parameters span from a minimum of -55°C up to a maximum of 175°C, allowing use in diverse industrial environments with varying thermal demands. The device withstands peak non-repetitive forward surge currents up to 75 A, providing protection against transient overloads.

The MSC010SDA170B is compliant with RoHS requirements, ensuring environmentally safe manufacturing processes without hazardous substances. Its low leakage current and avalanche energy rating further contribute to device longevity and stable operation under electrical stress.

This component is selected for industrial, commercial, and laboratory power supply designs, switch mode power supplies, and other semiconductor-based rectification applications requiring reliable Schottky diodes with high voltage and current ratings.

The diode utilizes through-hole mounting in a TO-247 package for straightforward PCB integration. High continuous forward current of 10 A supports demanding power circuits. Peak reverse voltage of 1700 V provides robust blocking capability.

Low forward voltage drop reduces power dissipation for efficient operation. Wide operating temperature range ensures suitability for harsh conditions. High surge current capacity protects against short-term overloads. RoHS compliance aligns with environmental and safety standards.

Zero recovery silicon carbide technology allows for high-frequency switching performance. Explore more power semiconductor components for your industrial and laboratory needs on EnvMart.

Explore more products in our Schottky Diodes & Rectifiers category.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The maximum reverse repetitive voltage of the Microchip MSC010SDA170B is 1700 volts, providing robust voltage blocking capability.

This diode can handle a maximum continuous forward current of 10 amperes, suitable for sustained operation in power applications.

The maximum forward voltage drop for the MSC010SDA170B is 1.8 volts, which helps reduce power losses during conduction.

The peak non-repetitive forward surge current for this diode is rated at 75 amperes, allowing it to withstand transient overloads.

The operating temperature range for the MSC010SDA170B spans from -55°C to 175°C, making it suitable for various thermal environments.

This model utilizes a through-hole mount type, which is ideal for robust installations in power electronics applications.

The diode is housed in a TO-247 package format, facilitating straightforward PCB integration.

Yes, the MSC010SDA170B complies with RoHS standards, ensuring environmentally safe manufacturing processes.

It is designed with zero recovery silicon carbide technology, enabling high-frequency switching performance.

This diode is selected for industrial, commercial, and laboratory power supply designs, as well as switch mode power supplies and rectification applications.

The MSC010SDA170B is a Schottky rectifier, known for its low forward voltage drop and fast switching capabilities.

Key features include a maximum reverse voltage of 1700V, a forward current rating of 10A, a low forward voltage drop of 1.8V, and compliance with RoHS standards.
