Microchip 1200 V 10 A Schottky Barrier Diode TO-220 MSC010SDA120K
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Model | MSC010SDA120K |
| Mount Type | Through Hole |
| Series | MSC0 |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-220 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Maximum Continuous Forward Current If | 10A |
| Peak Reverse Repetitive Voltage Vrrm | 1200V |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 75A |
| Maximum Forward Voltage Vf | 1.8V |
Key Features
- Schottky barrier diode providing low forward voltage drop for efficient rectification.
- Rated maximum continuous forward current of 10 A for reliable performance.
- Peak reverse repetitive voltage up to 1200 V for high voltage applications.
- Low forward voltage of 1.8 V to reduce power loss.
- Wide operating temperature range from -55°C to 175°C for industrial use.
- High surge current capability of 75 A to withstand transient conditions.
- RoHS compliant for environmental safety and industry standards.
- Through hole mount type suitable for robust PCB assembly.
Product Description
Microchip MSC010SDA120K is a Schottky barrier diode designed for high voltage industrial and electronic semiconductor applications. It combines advanced silicon carbide technology to increase performance compared to conventional silicon diodes while lowering overall cost of ownership.
This diode features a robust TO-220 package suitable for through-hole mounting, enabling stable installation on power boards. It has a maximum continuous forward current rating of 10 A and a peak reverse repetitive voltage rating of 1200 V, making it ideal for high voltage rectification tasks in power supply circuits and switching power devices.
The device offers low forward voltage (1.8 V) and minimal leakage current due to Schottky barrier technology, ensuring higher efficiency and reduced thermal dissipation in industrial power electronics. It supports a wide operating temperature range from -55°C to 175°C, fitting diverse environmental conditions encountered in manufacturing, automotive, and energy sectors.
With a peak non-repetitive forward surge current rating of 75 A, the MSC010SDA120K withstands transient power surges, enhancing reliability in rigorous applications. Fully RoHS compliant, it meets environmental regulatory standards.
Schottky barrier diode providing low forward voltage drop for efficient rectification. Maximum continuous forward current of 10 A supports moderate power applications. High peak reverse repetitive voltage rating of 1200 V ensures operation in high voltage circuits.
Wide operating temperature range from -55°C to 175°C supports industrial environments. Robust TO-220 through hole package for effective heat dissipation and mounting durability. High surge current tolerance of 75 A for transient stability.
RoHS compliant for environmental and safety regulations. Ideal for use in power supplies, switching circuits, and power conditioning systems.
This product is categorized under Schottky Barrier Diodes, suitable for industrial, manufacturing, electronic assembly, power conversion, and semiconductor equipment applications. Explore related Microchip components and semiconductor products on EnvMart for comprehensive project solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of the MSC010SDA120K is 10 A.
This model has a peak reverse repetitive voltage rating of 1200 V, suitable for high voltage applications.
The maximum forward voltage drop for this diode is 1.8 V, which helps reduce power loss during operation.
It operates within a wide temperature range from -55°C to 175°C, making it suitable for various industrial environments.
The MSC010SDA120K features a through hole mount type, which is suitable for robust PCB assembly.
This diode can withstand a peak non-repetitive forward surge current of 75 A, enhancing its reliability in transient conditions.
It comes in a TO-220 package type, which is designed for effective heat dissipation and mounting durability.
Yes, the MSC010SDA120K is RoHS compliant, meeting environmental and safety regulations.
This Schottky barrier diode is suitable for applications in power supplies, switching circuits, and power conditioning systems.
The MSC010SDA120K belongs to the MSC0 series of Schottky barrier diodes.
The country of origin for this diode is India.
This model is a Schottky rectifier, known for its low forward voltage drop and efficiency in rectification tasks.
