| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 0.8mm |
| Length | 1.8mm |
| Model | PMEG4005EJ,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | PMEG4005EJ |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323F |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 500mA |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 10A |
| Maximum Forward Voltage Vf | 470mV |
| onsemi 40 V 250 mA Diode Schottky 2-Pin SOD-323 NSR0240HT1GBrand | onsemi |
Nexperia PMEG4005EJ,115 is a Schottky barrier diode designed for efficient rectification in electronic circuits. This surface-mount device (SMD) utilizes a 2-pin SOD-323F package, making it suitable for compact and space-constrained PCB layouts.
The diode supports a maximum continuous forward current of 500 mA and a peak reverse repetitive voltage rating of 40 V, ensuring reliable performance in low power switching and rectifier applications. Its low forward voltage drop of 470 mV minimizes power dissipation and improves energy efficiency.
This Schottky diode offers a peak non-repetitive forward surge current of 10 A and operates across a wide temperature range from -65°C to 150°C, providing robustness in various industrial and commercial operating environments.
Physical dimensions are compact at 1.8 mm in length, 1.35 mm in width, and 0.8 mm in height, enabling use in densely packed electronic assemblies. The device’s low capacitance and minimal leakage current further enhance its performance in high-frequency switching circuits.
Typical applications include power conversion, voltage clamping, rectify low-voltage signals, and use in power management circuits for consumer electronics, automotive electronics (non-automotive standard), and instrumentation.
The diode features single diode configuration optimized for low forward voltage drop. Packaged in a thin, ultra-small SOD-323F surface mount package. Ensures high efficiency and low power switching losses. Reliable operation over a wide temperature range from -65°C to 150°C.
Peak non-repetitive surge current capability of 10 A. Manufactured in China with industrial-grade quality. Compact two-pin design facilitates PCB layout and assembly.
This Nexperia diode is ideal for integration in industrial electronics, telecommunications, power supply units, and switching power applications, meeting the demand for efficient and compact Semiconductors.
Explore further components and complementary products in the Schottky Diodes category at EnvMart to support your electronic design needs.
