ROHM Single Switching Diode, 215 mA Forward Current, 80 V Max Reverse Voltage, SOT-23 Package BAV170HYFHT116

Free Delivery in India | Lowest Global Shipping Charges

ROHM Single Switching Diode, 215 mA Forward Current, 80 V Max Reverse Voltage, SOT-23 Package BAV170HYFHT116

Name: ROHM Single Switching Diode, 215 mA Forward Current, 80 V Max Reverse Voltage, SOT-23 Package BAV170HYFHT116
Brand: ROHM
SKU: 291675
Price: 0.07 USD
Availability: InStock



Category Switching Diode Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Height	1.15mm
Length	3.1mm
Model	BAV170HYFHT116
Width	2.6mm
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOT-23
Sub Type	Switching Diode
Minimum Operating Temperature	-65°C
Pin Count	3
Maximum Power Dissipation Pd	250mW
Diode Configuration	Single
Peak Non-Repetitive Forward Surge Current Ifsm	4A
Maximum Forward Voltage Vf	1.25V
Peak Reverse Recovery Time trr	3μs
Maximum Forward Current If	215mA
Maximum Peak Reverse Repetitive Voltage Vrrm	80V

Key Features

The diode features a compact SOT-23 package suitable for dense PCB layouts.
Maximum power dissipation is 250 mW ensuring reliable operation under rated conditions.
Peak reverse recovery time of 3 microseconds enhances switching performance.
Operating temperature range is from -65°C to 150°C for extended environment use.
It has a maximum forward voltage drop of 1.25 V for efficient conduction.
Supports a peak non-repetitive forward surge current of 4 A for transient protection.
Three-pin configuration allows easy surface mounting and integration into circuits.
Typically employed in general switching applications in electronic devices.

Product Description

ROHM BAV170HYFHT116 is a Single Switching Diode designed with a maximum forward current of 215 mA and a peak reverse voltage rating of 80 V, packaged in a small SOT-23 surface-mount format.

This diode offers high reliability and low IR making it suitable for various switching applications in industrial electronics, power management, and semiconductor circuits.

The compact SOT-23 package, measuring 3.1 mm in length, 2.6 mm in width, and 1.15 mm in height, allows efficient PCB space utilization. Its peak reverse recovery time of 3 μs enables fast switching speeds, enhancing circuit performance.

With a maximum power dissipation of 250 mW and an operating temperature range of -65°C to 150°C, this diode is built to withstand demanding thermal environments, ensuring durability in industrial and commercial electronic devices.

The maximum forward voltage drop of 1.25 V minimizes power loss during conduction, while the peak non-repetitive forward surge current rating of 4 A provides robustness against transient electrical spikes.

This ROHM Switching Diode is ideal for use in discrete semiconductor applications including switching circuits, power supplies, and signal rectification in electronics manufacturing and industrial automation.

The diode features a compact SOT-23 package suitable for dense PCB layouts. Maximum power dissipation is 250 mW ensuring reliable operation under rated conditions. Peak reverse recovery time of 3 microseconds enhances switching performance.

Operating temperature range is from -65°C to 150°C for extended environment use. It has a maximum forward voltage drop of 1.25 V for efficient conduction. Supports a peak non-repetitive forward surge current of 4 A for transient protection.

Three-pin configuration allows easy surface mounting and integration into circuits. Typically employed in general switching applications in electronic devices. Explore more semiconductor diodes and electronic components in the Electronics & Electricals category at EnvMart.
