Panasonic Shielded Wirewound Surface Mount Inductor Metal Composite Core 330 nH ±20 % 12.7 A Idc ETQP3M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 3mm |
| Length | 5.5mm |
| Model | ETQP3M |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | ETQP3M |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 330nH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 12.7A |
| Pin Count | 2 |
| Maximum DC Resistance | 5.34mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a metal composite core to ensure high heat resistance and reliability.
- Features shielded wirewound construction for excellent inductance stability.
- Rated for operation up to 155°C, suitable for high-temperature applications.
- Complies with AEC-Q200 automotive standard, ensuring durability and quality.
- Available in a compact 5.5mm length, 3mm height, and 5mm depth surface mount package.
- Surface mount termination style with tape and reel packaging for manufacturing efficiency.
- Low maximum DC resistance of 5.34 mΩ contributes to minimal power loss.
- Ideal for use as noise filters in drive circuitry requiring high temperature and peak current handling capabilities.
Product Description
Panasonic ETQP3M Shielded Wirewound Surface Mount Inductor is designed with a metal composite core providing high heat resistance and exceptional reliability in demanding electronic environments. The wirewound construction and shielding offer excellent inductance stability with reduced audible noise.
With an inductance of 330 nH ±20 % tolerance and a maximum DC current of 12.7 A, this inductor is capable of handling peak current situations and high bias currents while maintaining temperature stability up to 155°C. It passes the stringent automotive AEC-Q200 standard, making it suitable for automotive and industrial electronics.
The compact dimensions of 5.5mm length, 3mm height, and 5mm depth enable space-saving PCB layouts. Surface mount termination style and tape & reel packaging facilitate automated assembly processes, enhancing production efficiency. Its low DC resistance of 5.34mΩ minimizes power loss and heat generation.
This inductor is ideal as a noise filter for various high-temperature drive circuitry and other applications requiring stable inductance and high reliability. Its molded construction further enhances vibration resistance, providing durable performance even in harsh conditions.
Constructed with metal composite core offering high heat resistance. Shielded wirewound design reduces electromagnetic interference. Supports operation in wide temperature range from -55°C to 155°C. Compliant with RoHS, ensuring environmental compatibility.
Automotive grade AEC-Q200 certified for quality assurance. Surface mount package supports modern automated assembly. Low DC resistance for efficient electrical performance. High current rating of 12.7 A suitable for demanding circuits.
Available for various industrial, automotive, and electronic applications requiring reliable inductors with high current, temperature, and noise filtering needs. Explore more Surface Mount Inductors and electronic components at EnvMart for your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 330 nH with a tolerance of ±20%.
It has a maximum DC current rating of 12.7 A, making it suitable for demanding circuits.
The dimensions are 5.5 mm in length, 3 mm in height, and 5 mm in depth.
This inductor operates within a temperature range of -55°C to 155°C.
It is constructed with a metal composite core, providing high heat resistance and reliability.
The termination style is surface mount, which is suitable for automated assembly processes.
The maximum DC resistance is 5.34 mΩ, contributing to minimal power loss.
Yes, it complies with the AEC-Q200 automotive standard and RoHS for environmental compatibility.
It features a wirewound construction, which enhances inductance stability and reduces noise.
It is packaged in tape and reel format, facilitating efficient manufacturing processes.
It is ideal for use as noise filters in high-temperature drive circuitry and other demanding electronic applications.
This model has a pin count of 2, suitable for surface mount configurations.
