Panasonic ECQUB Polypropylene Capacitor, ±10 %, 1.2 nF 300V AC Through Hole ECQUBAF122K
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 11.5mm |
| Length | 15.3mm |
| Model | ECQUBAF122K |
| Width | 5mm |
| Mount Type | Through Hole |
| Series | ECQUB |
| Maximum Operating Temperature | 110°C |
| Tolerance | ±10 % |
| Capacitance | 1.2nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Straight |
| Dissipation Factor | 0.1% |
| Lead Length | 20mm |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 300V ac |
| Lead Pitch | 12.5mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with metallized polypropylene film for non-inductive performance.
- Rated operating temperature range from -40°C to 110°C suitable for various electronic applications.
- Features a flame-retardant plastic case with non-combustible resin for enhanced safety.
- Lead pitch of 12.5 mm and lead length of 20 mm with straight terminal type provides secure mounting.
- High moisture resistance and compliance with automotive standard AEC-Q200 ensures durability.
- Dissipation factor of 0.1% enables efficient operation with minimal energy loss.
- Dimensioned at 15.3 mm length, 11.5 mm height, and 5 mm width for compact installation.
- Pin count is 2 with lead diameter of 0.6 mm suited for interference suppression in electronic equipment.
Product Description
Panasonic ECQUBAF122K is a high-quality metallized polypropylene film capacitor engineered for interference suppression in electronic equipment. With a capacitance of 1.2 nF and a rated AC voltage of 300V, it is designed for through hole mounting applications.
This capacitor features a flame-retardant plastic case and non-combustible resin to ensure safety and reliability in demanding environmental conditions. Designed to operate within a temperature range of -40°C to 110°C, it satisfies automotive standard AEC-Q200 requirements, making it suitable for automotive and industrial use.
The capacitor uses a straight terminal type with a lead pitch of 12.5 mm and a lead length of 20 mm, facilitating robust and reliable through hole connections. With a dissipation factor of 0.1%, it offers excellent energy efficiency and low heat generation during operation.
Its compact dimensions of 15.3 mm length, 11.5 mm height, and 5 mm width enable versatile mounting in various circuit board layouts. The sturdy 2-pin design includes 0.6 mm lead diameters for enhanced electrical performance and mechanical stability.
Constructed using metallized polypropylene film for high electrical performance. Flame retardant and non-combustible casing enhances safety standards. Wide operating temperature range ensures performance in harsh environments.
Meets automotive standard AEC-Q200 for automotive and industrial applications. Optimized lead dimensions and pitch for secure through-hole mounting. Low dissipation factor minimizes energy loss. Designed for interference suppression in electronic systems.
This Panasonic ECQUB series capacitor is RoHS compliant and manufactured in China, guaranteeing quality and environmental compliance. Ideal for industrial, automotive, electronic, and manufacturing equipment applications.
Explore more film capacitors with advanced specifications and trusted brands at EnvMart for your electronic component sourcing needs.
Explore more products in our Passive Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 1.2 nF.
It has a rated AC voltage of 300V.
The operating temperature range is from -40°C to 110°C.
The lead length is 20 mm and the lead pitch is 12.5 mm.
This capacitor is designed for through hole mounting applications.
The dissipation factor is 0.1%.
It has a pin count of 2.
The dimensions are 15.3 mm in length, 11.5 mm in height, and 5 mm in width.
It features a straight terminal type.
Yes, it complies with automotive standard AEC-Q200.
It is constructed with metallized polypropylene film and features a flame-retardant plastic case.
This capacitor is manufactured in China.
