TE Connectivity 3650 0603 Wirewound Surface Mount Inductor 180nH ±5% Tolerance 250mA DC Current Q:25 125°C 36501JR18JTDG

TE Connectivity 36501JR18JTDG is a 0603 size wirewound surface mount inductor with an inductance of 180nH and a tolerance of ±5%. It supports a maximum DC current of 250mA and operates reliably from -40°C to 125°C, making it suitable for industrial and commercial electronic applications.

The high quality wirewound construction provides excellent stability and low resistance with a maximum DC resistance of 1.4Ω. This inductor's high self-resonant frequency of 1.25GHz and a minimum quality factor of 25 makes it ideal for use in radio frequency (RF) circuitry, filtering, and tuning applications.

Its compact 0603 package size with dimensions length 1.8mm, height 1.02mm, and depth 1.12mm supports densely populated PCBs with surface mount technology. The two-pin termination style ensures secure soldering and reliable electrical conductivity.

Packaged on reels, these inductors allow efficient automated assembly processes for manufacturing electronic devices. Additionally, it meets RoHS compliance requirements, ensuring environmental safety by limiting hazardous substances.

Manufactured in Taiwan, these inductors are trusted components for electronics manufacturing, including telecommunications, automotive electronics, industrial equipment, and consumer devices. The 3650 series by TE Connectivity offers a high-performance solution for engineers demanding precision and reliability in passive components.

This 0603 package surface mount inductor features wirewound construction for high stability. Designed to operate at temperatures from -40°C up to 125°C ensuring durability. Provides a maximum DC resistance of 1.4 Ohms to maintain performance.

Offers a high self-resonant frequency up to 1.25GHz suitable for RF circuits. Comes on a reel packaging facilitating easy automatic PCB assembly. Contains 2 pins with a compact length of 1.8mm, height of 1.02mm, and depth of 1.12mm.

Complies with RoHS standards and is manufactured in Taiwan, Province Of China. Explore more Surface Mount Inductors and other Passive Components for efficient electronic circuit designs on EnvMart.
