Panasonic ECQUB Polypropylene Capacitor 3.9nF ±20% 300V AC Through Hole ECQUBAF392M
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 11.5mm |
| Length | 15.3mm |
| Model | ECQUBAF392M |
| Width | 5mm |
| Mount Type | Through Hole |
| Series | ECQUB |
| Maximum Operating Temperature | 110°C |
| Tolerance | ±20 % |
| Capacitance | 3.9nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Straight |
| Dissipation Factor | 0.1% |
| Lead Length | 20mm |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 300V ac |
| Lead Pitch | 12.5mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
Key Features
- Capacitance value of 3.9nF suitable for filtering and tuning circuits.
- Rated AC voltage of 300 volts ensures reliable operation in electronic equipment.
- Through-hole mount type with straight terminals for easy PCB installation.
- Operating temperature range from -40°C to 110°C for versatile applications.
- Lead pitch of 12.5mm and lead length of 20mm for standard fitting.
- Complies with automotive standard AEC-Q200 for quality assurance.
- Flame-retardant plastic case provides enhanced safety and durability.
- Dissipation factor of 0.1% indicating low energy loss.
Product Description
Panasonic ECQUBAF392M is a polypropylene film capacitor with a capacitance of 3.9 nanofarads and a tolerance of ±20%. It is rated for an AC voltage of 300 volts and utilizes through-hole mounting with straight terminals. The capacitor features a flame-retardant plastic case and a non-inductive metallized polypropylene film construction, ensuring high safety and moisture resistance.
This ECQUB series capacitor supports operation in a temperature range from -40°C to 110°C and meets automotive standard AEC-Q200, suitable for use in automotive and industrial electronic equipment. It exhibits a low dissipation factor of 0.1%, making it efficient in interference suppression applications.
Its compact size with dimensions of 15.3mm length, 11.5mm height, and 5mm width along with a lead pitch of 12.5mm and lead length of 20mm facilitate easy integration on printed circuit boards. The capacitor complies with international safety standards including CSA, EN, and UL certification requirements.
This Panasonic polypropylene film capacitor is an excellent choice for electronic component engineers seeking reliable performance in power and signal conditioning circuits. It supports robust usage conditions in industrial, automotive, and consumer electronics environments.
Capacitance: 3.9nF ±20% tolerance. Rated AC Voltage: 300V AC. Mount type: Through Hole with straight terminals. Operating temperature: -40°C to 110°C. Lead pitch: 12.5mm; lead length: 20mm. Flame-retardant plastic casing for safety.
Meets AEC-Q200 automotive standard. Compliant with CSA E60384-14, EN 60384-14, UL 60384-14. Low dissipation factor of 0.1% ensures efficient performance. Compact size with 15.3mm length, 11.5mm height, and 5mm width. Manufactured in China.
Explore more high-quality capacitors like the Panasonic ECQUB series in the Film Capacitors category at EnvMart for industrial, automotive, and commercial electronics applications.
Explore more products in our Passive Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 3.9 nanofarads (nF) with a tolerance of ±20%.
It is rated for an AC voltage of 300 volts.
The operating temperature range is from -40°C to 110°C.
This unit utilizes through-hole mounting with straight terminals.
The dimensions are 15.3mm in length, 11.5mm in height, and 5mm in width.
The lead length is 20mm, and the lead pitch is 12.5mm.
It has a low dissipation factor of 0.1%, indicating efficient performance.
Yes, it complies with the automotive standard AEC-Q200.
It features a flame-retardant plastic case and a non-inductive metallized polypropylene film construction.
It is manufactured in China.
This model is suitable for filtering and tuning circuits in automotive and industrial electronic equipment.
It complies with international safety standards including CSA, EN, and UL certification requirements.
