ROHM ESD 2-Element Bi-Directional ESD Protection Diode 3-Pin SOT-23 100 W ESD18VHYFHT116
Specifications
| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Model | ESD18VHYFHT116 |
| Mount Type | Surface |
| Series | ESD18VHYFH |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS, AEC-Q101 |
| Pin Count | 3 |
| Number of Elements per Chip | 2 |
| Clamping Voltage VC | 16V |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 19.74V |
| Maximum Reverse Stand-off Voltage Vwm | 16V |
| Peak Pulse Power Dissipation Pppm | 100W |
| Test Current It | 1mA |
| Maximum Reverse Leakage Current | 100nA |
Key Features
- Bi-directional ESD protection diode suitable for automotive and industrial electronics.
- Supports peak pulse power dissipation up to 100 W for robust surge handling.
- Minimum breakdown voltage of 19.74 V and maximum reverse stand-off voltage of 16 V.
- Compact SOT-23 surface-mount package with three pins.
- Wide operating temperature range from -55°C to 150°C for harsh environments.
- Low maximum reverse leakage current of 100 nA to reduce power loss.
- AEC-Q101 qualified and RoHS compliant ensuring automotive-grade reliability.
- Clamping voltage of 16 V to protect circuits from voltage spikes.
Product Description
ROHM ESD18VHYFHT116 is a high-reliability 2-element bi-directional electrostatic discharge (ESD) protection diode designed for surface mount applications in demanding automotive and electronic devices. Packaged in a compact 3-pin SOT-23 form factor, this diode offers robust protection against voltage spikes and transient surges, capable of dissipating peak pulse power up to 100 W.
With a minimum breakdown voltage (Vbr) of 19.74 V and maximum reverse working voltage (VRWM) of 16 V, it protects sensitive circuits effectively while maintaining low leakage currents of 100 nA, minimizing power loss and thermal stresses. This diode supports a wide operating temperature range from -55°C to 150°C, suitable for harsh industrial and automotive environments.
The device conforms to AEC-Q101 standards and is RoHS compliant, ensuring quality and environmental safety. Its small mold type design allows easy surface mounting and space-saving PCB layouts, while the ±30kV ESD protection level according to IEC61000-4-2 contact discharge provides superior surge immunity.
Applications include automotive electronics, industrial controls, and consumer electronics needing reliable surge and ESD protection. Its bidirectional configuration allows protection on both positive and negative voltage transients.
Bi-directional ESD Protection Diode suitable for automotive and industrial electronics. Supports peak pulse power dissipation up to 100 W for robust surge handling. Minimum breakdown voltage of 19.74 V and maximum reverse stand-off voltage of 16 V.
Compact SOT-23 surface-mount package with three pins. Wide operating temperature range from -55°C to 150°C for harsh environments. Low maximum reverse leakage current of 100 nA to reduce power loss. AEC-Q101 qualified and RoHS compliant ensuring automotive-grade reliability.
Clamping voltage of 16 V to protect circuits from voltage spikes. Test current rating of 1 mA for surge testing. Small mold type package with high surge resistance and ±30kV ESD protection level (IEC61000-4-2 Contact).
This ROHM diode is ideal for use in automotive, industrial, and other applications requiring durable ESD protection components integrated into compact electronic assemblies. Browse our comprehensive semiconductor category for related ROHM components and innovative solutions to meet your surge protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports peak pulse power dissipation up to 100 W, allowing it to handle robust surge conditions effectively.
The minimum breakdown voltage of this diode is 19.74 V, ensuring effective protection for sensitive circuits.
The maximum reverse stand-off voltage is 16 V, which helps in safeguarding circuits against voltage spikes.
It operates within a wide temperature range from -55°C to 150°C, making it suitable for harsh environments.
The clamping voltage is 16 V, providing a safeguard against voltage transients.
The maximum reverse leakage current is 100 nA, which helps to reduce power loss in the circuit.
This diode comes in a compact SOT-23 package type with three pins, facilitating easy surface mounting.
Yes, it is AEC-Q101 qualified and RoHS compliant, ensuring automotive-grade reliability and environmental safety.
The test current rating for this model is 1 mA, which is used during surge testing to evaluate performance.
It is suitable for automotive electronics, industrial controls, and consumer electronics that require reliable surge and ESD protection.
This diode provides bi-directional ESD protection, allowing it to protect against both positive and negative voltage transients.
The country of origin for this diode is India.
