STMicroelectronics Schottky Diode 2-Pin SOD-523 30 V 300 mA Surface Mount BAT30KFILM

STMicroelectronics BAT30KFILM Schottky Diode is a compact and efficient 2-pin device housed in a SOD-523 surface mount package. It offers a maximum continuous forward current of 300 mA and a peak reverse repetitive voltage of 30 V, making it suitable for use in a variety of low power electronic circuits where efficient rectification and low forward voltage drop are critical.

This diode is designed for industrial and commercial semiconductor applications including electronic components, power connectors, and discrete semiconductors. Its low forward voltage (580 mV max) increases overall circuit efficiency by minimizing power loss during conduction.

The diode's compact footprint of 1.3 mm length by 0.9 mm width and height of 0.7 mm supports high-density PCB layouts. Its robust construction enables operation up to 150°C, which supports harsh operational environments. The device features a low peak reverse current of 50 μA, lowering leakage currents and enhancing longevity of devices.

Additional robustness is provided by its tolerance to a peak non-repetitive forward surge current of 1 A, allowing it to handle transient voltage spikes without damage. It is highly recommended for applications requiring efficient Schottky barrier diode performance in a surface mount format.

Compact 2-pin SOD-523 surface mount package. Maximum continuous forward current of 300 mA. Reverse voltage rating of 30 V. Maximum forward voltage of 580 mV. Operating temperature range up to 150°C. Low peak reverse current of 50 μA.

Peak surge current of 1 A. Small dimensions for dense PCB layout. Manufactured in China for quality assurance. Suitable for semiconductor, power, and electronic component applications. Explore more top-quality Schottky Diodes and Rectifiers to enhance your electronics projects and industrial designs on EnvMart.
