| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1.35mm |
| Length | 2.85mm |
| Model | BAT46W-7-F |
| Width | 1.7mm |
| Mount Type | Surface |
| Series | BAT46W |
| Maximum Operating Temperature | 125°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | FBI |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 150mA |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 20μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 750mA |
| Maximum Forward Voltage Vf | 1V |
DiodesZetex BAT46W-7-F is a high-performance Schottky diode designed for surface mounting in electronic devices requiring efficient rectification with low forward voltage drop. The device supports a peak reverse voltage of 100 V and a continuous forward current rating of 150 mA, making it suitable for low-power applications.
Housed in a compact 2-pin SOD-123 package measuring 2.85 mm in length, 1.7 mm in width, and 1.35 mm in height, the diode facilitates dense PCB layouts without compromising reliability. Its maximum forward voltage drop of 1 V improves power efficiency and reduces heat dissipation during operation.
The diode operates effectively in harsh environmental conditions with operational temperature limits ranging from -55°C to 125°C, ensuring durable performance in automotive and industrial settings. It conforms to the AEC-Q101 automotive qualification standard and FBI regulatory standards, verifying its high quality and reliability.
This single configuration Schottky diode features a peak reverse current of only 20 μA, minimizing leakage currents and improving circuit stability. It can tolerate surge currents up to 750 mA non-repetitively, protecting downstream components from transient events.
Ideal for power management, switching, and protection circuits in telecommunications, industrial automation, automotive electronics, and consumer devices, the BAT46W-7-F diode is a versatile choice for designers seeking compact, reliable diode solutions.
Low forward voltage drop ensures efficient rectification. Wide operating temperature range suitable for industrial and automotive use. Compact surface mount SOD-123 package facilitates space-saving PCB designs. Automotive grade compliance with AEC-Q101 enhances durability.
High surge current capacity protects circuits from transient damage. Minimal leakage current maintains circuit integrity. Single diode configuration supports various application needs. RoHS compliant for environmental safety.
Meets FBI standards for quality assurance. Explore our extensive semiconductor diode range on EnvMart to find components ideal for your industrial, laboratory, automotive, or consumer electronics requirements.
Explore more products in our Semiconductor Diodes category.
