DiodesZetex 150 V 10 A General Purpose 3-Pin Surface Mount TO-252 Diode SBR10150CTL-13
Specifications
| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 2.39mm |
| Length | 6.7mm |
| Model | SBR10150CTL-13 |
| Width | 6.2mm |
| Mount Type | Surface |
| Series | 10A SBR |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | FBI |
| Pin Count | 3 |
| Automotive Standard | AEC |
| Maximum Continuous Forward Current If | 10A |
| Peak Reverse Repetitive Voltage Vrrm | 150V |
| Diode Configuration | Common Cathode |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 20mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 110A |
| Maximum Forward Voltage Vf | 940mV |
Key Features
- Designed for high efficiency and low forward voltage drop of approximately 940mV.
- Supports maximum continuous forward current of 10 amperes for robust operation.
- Operates reliably within temperature range from -65°C to 150°C.
- Features peak reverse repetitive voltage of 150 volts suitable for power applications.
- Common cathode diode configuration in a compact 6.7 x 6.2 x 2.39 mm form factor.
- Peak non-repetitive forward surge current rating of 110 amperes.
- Complies with AEC automotive standard and FBI approval ensuring quality assurance.
- Ideal for industrial, automotive, power supply, and electronic circuit designs.
Product Description
DiodesZetex SBR10150CTL-13 is a general purpose Schottky diode engineered for power and electronic device applications requiring efficient rectification and low forward voltage drop.
This diode is housed in a surface mount TO-252 package featuring three pins and a compact profile with dimensions of 6.7 mm length, 6.2 mm width, and 2.39 mm height.
Key electrical ratings include a maximum continuous forward current of 10 A and peak reverse repetitive voltage of 150 V, making it suitable for moderate power rectification duties.
The device supports a peak non-repetitive forward surge current of 110 A and a typical maximum forward voltage of 940 mV, contributing to improved thermal performance and efficiency.
The operating temperature range spans from -65°C to 150°C, ensuring reliability in harsh environments and automotive applications. The diode features a common cathode configuration and complies with automotive standards (AEC) and FBI approvals for quality assurance.
Designed for efficient rectification with low forward voltage drop. Robust current handling up to 10 A continuously. High surge current capacity up to 110 A. Wide operating temperature range for industrial and automotive use.
Compact 3-pin surface mount TO-252 package for PCB mounting. Complies with relevant automotive and industry standards. Suitable for power supply, industrial, and electronic circuit applications.
This diode is manufactured in China and is supplied new. It is essential for use in various electronic assemblies requiring reliable Schottky barrier diodes with high current capacity and low forward voltage losses.
For additional electronic component selections, explore the semiconductors and diode categories on EnvMart for high-quality industrial-grade components.
Explore more products in our Semiconductor Diodes category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the SBR10150CTL-13 is 10 amperes.
This model has a peak reverse repetitive voltage rating of 150 volts, making it suitable for power applications.
The typical maximum forward voltage drop is approximately 940 mV.
The dimensions of the TO-252 package are 6.7 mm in length, 6.2 mm in width, and 2.39 mm in height.
It operates reliably within a temperature range from -65°C to 150°C.
The peak non-repetitive forward surge current rating is 110 amperes.
This diode features a common cathode configuration.
It complies with AEC automotive standards and has FBI approval, ensuring quality assurance.
This diode is suitable for industrial, automotive, power supply, and electronic circuit designs.
The SBR10150CTL-13 has a pin count of 3.
This diode is manufactured in China.
This model is classified as a general purpose rectifier.
