Murata Power Solutions Surface Mount Common Mode Choke 2.2 mH 500 mA 7mm Length 50225C

Murata Power Solutions 50225C Surface Mount Common Mode Choke is a compact, wirewound inductive component designed for attenuation of common mode noise in electronic circuits. Featuring a 2.2 mH inductance and a maximum DC current capability of 500 mA, this inductor is ideal for low current switching power supplies and telecom applications where line filtering up to 100 MHz is required.

The device presents an inductance tolerance of -30 to 50 percent and a maximum DC resistance of 400 milliohms, ensuring efficient current handling and low power loss. It is constructed with pure tin dip termination style on a surface mount package for ease of automated PCB assembly.

Operating reliably between temperatures of -40°C to 85°C, this surface mount choke measures 7 mm in length, 3.6 mm in height, and 5.9 mm in depth, with a 4-pin configuration. Its packaging material meets UL94 V-0 flammability standards and is RoHS compliant, affirming both safety and environmental compliance. Manufactured in China, this inductor supports diverse industrial, laboratory, telecom, and electronic manufacturing use cases.

Applications include noise suppression in switching power supplies, telecom equipment, and other low current electronic systems requiring compact, reliable common mode chokes. This part helps improve electromagnetic compatibility and reduces interference in sensitive circuits.

Set comes as a single unit packaged for surface mount insertion with a compact form factor suitable for high volume assembly processes. Compact surface mount design for efficient line filtering. Inductance tolerance ranges from -30 to 50 percent.

Maximum DC resistance of 400 milliohms ensures low loss operation. Operates reliably between -40°C and 85°C. Constructed with wirewound inductors and pure tin dip termination. UL94 V-0 rated packaging material provides flame retardancy.

Measures 7 mm length, 3.6 mm height, and 5.9 mm depth. Pin count of 4 designed for surface mount PCB applications. RoHS compliant with manufacturing origin in China.
