Murata Power Solutions Through Hole Pulse Transformer 1:1.33 Turns Ratio, 310 μH Primary Inductance, 600mΩ 782482/33VC

Murata Power Solutions 782482/33VC is a high-quality through hole pulse transformer featuring a primary inductance of 310 μH and a primary DC resistance of 600mΩ. This component offers a 1:1.33 turns ratio and an isolation voltage rating of 4000 V, making it suitable for isolating and converting electrical signals in various electronic circuits.

Its compact dimensions (6.35mm length, 9.14mm width, and 9.77mm depth) and light weight of 1.1 grams allow for easy integration into PCBs via through hole mounting with six connecting pins. The transformer delivers reliable performance across an operating temperature range from -40°C to 85°C, complying with RoHS environmental standards.

Designed especially for communication applications, it is compatible with Analog Devices' AMD2452E RS485/232 isolation converter IC. The low leakage inductance of 8 μH helps minimize signal degradation, ensuring signal integrity in industrial, laboratory, and telecommunications environments. This transformer is well-suited for isolated RS-485 and RS-232 interface designs requiring robust electrical isolation.

1:1.33 turns ratio providing optimum signal conversion efficiency. High isolation voltage of 4000 V for safety and circuit protection. Through hole mount type with standard pin configuration for easy installation. Compliance with RoHS standards for environmental safety.

Compact size and low weight for space-constrained PCB layouts. Wide operating temperature range for versatile industrial use. Compatible with AMD2452E isolation converter IC. Low leakage inductance minimizes signal loss and noise.

This pulse transformer is ideal for use in industrial machines, telecommunication systems, laboratory equipment, and other electronic control applications where reliable signal isolation is critical. Its robust construction and excellent electrical performance make it a dependable choice for engineers and manufacturers.
