STMicroelectronics 1-Element Uni-Directional TVS Diode 600 W 2-Pin DO-214 SMBJ26A-TR

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics 1-Element Uni-Directional TVS Diode 600 W 2-Pin DO-214 SMBJ26A-TR

Name: STMicroelectronics 1-Element Uni-Directional TVS Diode 600 W 2-Pin DO-214 SMBJ26A-TR
Brand: STMicroelectronics
SKU: 219294
Price: 0.16 USD
Availability: InStock



Category TVS Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	2.45mm
Length	4.6mm
Model	SMBJ26A-TR
Width	3.95mm
Mount Type	Surface
Series	SMBJ
Maximum Operating Temperature	150°C
Package Type	DO-214
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	53.5V
Diode Configuration	Single
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	28.9V
Maximum Reverse Stand-off Voltage Vwm	26V
Peak Pulse Power Dissipation Pppm	600W
Test Current It	1mA
Maximum Peak Pulse Current Ippm	75A
Maximum Reverse Leakage Current	200nA

Key Features

This diode has a single diode configuration for reliable uni-directional voltage suppression.
It features a minimum breakdown voltage of 28.9 V and a maximum reverse stand-off voltage of 26 V.
The package type is DO-214 with 2 pins optimized for surface mounted placement on PCBs.
It sustains peak pulse power dissipation of 600 W and a peak pulse current of 75 A for transient protection.
The clamping voltage during transients is rated at 53.5 V to safeguard connected electronics.
Operating temperature range is from -55°C to a maximum of 150°C for industrial environments.
Typical reverse leakage current is low at 200 nA ensuring minimal power loss during normal operation.
The device dimensions are 4.6 mm length, 3.95 mm width, and 2.45 mm height.

Product Description

STMicroelectronics SMBJ26A-TR is a 1-element uni-directional TVS (Transient Voltage Suppressor) diode designed for protecting sensitive electronic components from voltage spikes and transient surges. The device supports a peak pulse power dissipation of 600 W and comes in a DO-214 surface mount package with 2 pins.

This diode features a minimum breakdown voltage of 28.9 V and a maximum reverse stand-off voltage of 26 V, making it suitable for protecting circuits operating near these voltage levels. Its clamping voltage of 53.5 V ensures that transient voltages are suppressed effectively, preventing damage to semiconductors and other sensitive elements.

The SMBJ26A-TR operates reliably in a temperature range from -55°C to 150°C, making it suitable for a wide variety of industrial, commercial, and automotive electronic applications that require robust transient voltage protection.

The device's low maximum reverse leakage current of 200 nA contributes to energy efficiency and reduces stress on the power supply during normal operation. Its compact dimensions (4.6 mm × 3.95 mm × 2.45 mm) facilitate integration into densely populated circuit boards.

Single diode configuration optimized for uni-directional voltage suppression. Surface mount DO-214 package compatible with automated assembly processes. Maximum peak pulse current rating of 75 A for high transient surge handling.

Ideal for transient voltage protection in electronic circuits and power supplies. Suitable for industrial, power electronics, and semiconductor applications requiring high reliability. Compliance information and technical documents available for design assurance.
