STMicroelectronics 1-Element Bi-Directional TVS Diode 5 kW 2-Pin R-6 BZW50-100B

STMicroelectronics BZW50-100B is a single-element, bi-directional TVS (Transient Voltage Suppressor) diode that offers robust protection against voltage spikes in electronic circuits. With a peak pulse power dissipation rating of 5 kW and a 2-pin R-6 axial package, it is suitable for integration into through-hole mount applications requiring high-reliability surge suppression.

Featuring a minimum breakdown voltage of 111 V and a maximum reverse stand-off voltage of 100 V, this diode efficiently clamps transient voltages at 228 V to safeguard sensitive semiconductor components and circuit boards from damage caused by unexpected voltage surges.

The diode is designed to operate across a broad temperature spectrum from -65°C up to 175°C, making it suitable for industrial, automotive, and commercial electronic environments that encounter varying thermal conditions. Its compact physical dimensions, 9.1 mm in height, length, diameter, and width, allow versatile placement in tight PCB layouts.

With a peak pulse current capacity of 263 A and extremely low reverse leakage current of 5 μA, the BZW50-100B ensures effective transient suppression while maintaining power efficiency. This device adheres to industry norms but does not carry specific certifications, reinforcing its use in standard protection applications.

This diode is primarily used in electronic component manufacturing, power circuitry, and semiconductor protection systems within industrial, laboratory, automotive, and commercial applications requiring reliable transient voltage suppression.

Designed for surge protection in electronic circuits. Single diode configuration with bi-directional voltage suppression. Minimum breakdown voltage of 111 V to protect sensitive components. Through-hole mount with 2 pins for secure PCB connection.

Maximum reverse stand-off voltage rated at 100 V. Clamping voltage of 228 V ensures effective transient voltage suppression. Operates reliably between -65°C to 175°C for wide temperature range applications. Compact axial design with 9.1 mm dimensions for height, length, diameter, and width.

Peak pulse current up to 263 A supports high transient events. Low maximum reverse leakage current of 5 μA ensures minimal power loss. Explore more high-performance TVS Diodes and semiconductor devices in the Electronics & Electricals category on EnvMart for optimized circuit protection solutions.
