STMicroelectronics 1-Element Bi-Directional TVS Diode 600 W 2-Pin DO-214 SMBJ33CA-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.45mm |
| Length | 4.6mm |
| Model | SMBJ33CA-TR |
| Width | 3.95mm |
| Mount Type | Surface |
| Series | SMBJ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 69.7V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 36.7V |
| Maximum Reverse Stand-off Voltage Vwm | 33V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 57A |
| Maximum Reverse Leakage Current | 200nA |
Key Features
- Provides single-element bi-directional transient voltage suppression.
- Peak pulse power dissipation of 600 watts ensures robust transient handling.
- Minimum breakdown voltage of 36.7 V with a maximum reverse standoff voltage of 33 V.
- Compact surface mount DO-214 package measuring 4.6 mm length, 3.95 mm width, and 2.45 mm height.
- Operates reliably over a temperature range of -55°C to 150°C.
- Maximum peak pulse current of 57 A with a clamping voltage of 69.7 V.
- Low maximum reverse leakage current of 200 nA for minimal power loss.
- Designed for PCB surface mounting with 2 pins for easy integration.
Product Description
STMicroelectronics SMBJ33CA-TR is a single-element, bi-directional transient voltage suppression (TVS) diode designed to protect electronic circuits from voltage transients induced by inductive load switching and lightning.
This TVS Diode features a maximum peak pulse power dissipation of 600 W, enabling it to handle high energy transient events effectively. It operates with a minimum breakdown voltage of 36.7 V and a maximum reverse stand-off voltage of 33 V, providing reliable voltage clamping to safeguard sensitive components.
The device is packaged in a compact DO-214 surface mount package with dimensions of 4.6 mm in length, 3.95 mm in width, and 2.45 mm in height, making it suitable for high-density circuit board layouts. It incorporates a low maximum reverse leakage current of 200 nA, minimizing power consumption during normal operation.
Operating temperature range is -55°C to 150°C, ensuring stable performance under harsh conditions. The maximum peak pulse current rating of 57 A and clamping voltage of 69.7 V make it ideal for robust industrial, consumer electronics, automotive (non-automotive standard), and telecommunications transient protection needs.
Provides reliable transient voltage suppression with single-element bi-directional configuration. High pulse power rating withstands surge events effectively. Compact surface mount design facilitates automated assembly. Low leakage current conserves power in low standby applications.
Wide operating temperature range supports a variety of environments. Robust voltage ratings for effective protection of sensitive electronics. 2-pin design for simplified PCB mounting and integration. SMBJ series device, industry standard offering proven reliability.
This product is sourced from STMicroelectronics and is suitable for various electronic protection roles including industrial control equipment, telecommunications infrastructure, power supplies, and general purpose electronic assemblies.
Explore more semiconductor and diode solutions in the EnvMart catalogue for your industrial and electronic component sourcing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this TVS diode is 600 watts, enabling it to handle high energy transient events effectively.
The maximum reverse stand-off voltage for this model is 33 V, providing reliable voltage clamping to protect sensitive components.
The clamping voltage of this diode is 69.7 V, which helps in safeguarding electronic circuits during transient voltage events.
The minimum breakdown voltage of this unit is 36.7 V, ensuring effective clamping during voltage transients.
The DO-214 package measures 4.6 mm in length, 3.95 mm in width, and 2.45 mm in height, making it suitable for high-density circuit board layouts.
The maximum peak pulse current rating of this model is 57 A, allowing it to manage significant transient events effectively.
This diode operates reliably over a temperature range of -55°C to 150°C, ensuring stable performance under harsh conditions.
The SMBJ33CA-TR features a 2-pin design, which simplifies PCB mounting and integration.
This model uses a single-element bi-directional configuration, providing effective transient voltage suppression.
The maximum reverse leakage current for this diode is 200 nA, which minimizes power loss during normal operation.
This TVS diode is suitable for protecting industrial control equipment, telecommunications infrastructure, power supplies, and general electronic assemblies.
The country of origin for the SMBJ33CA-TR is India, indicating where it was manufactured.
