Wurth Elektronik WR-MJ Series RJ45 Connector Female, PCB Mount, Cat3 Nickel Plated Brass Shield Horizontal 1 Port 8 Way RJ45

Name: Wurth Elektronik WR-MJ Series RJ45 Connector Female, PCB Mount, Cat3 Nickel Plated Brass Shield Horizontal 1 Port 8 Way RJ45
Brand: Wurth Elektronik
SKU: 218270
Price: 1.49 USD
Availability: InStock



Category Ethernet Connector Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Brand	Wurth Elektronik
Orientation	Horizontal
Length	16.14mm
Model	RJ45
Depth	16mm
Connector Type	Modular Jack
Number Of Ways	8
Width	15.4mm
Mount Type	PCB
Contact Material	Copper Alloy
Series	WR-MJ
Number Of Ports	1
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Shield Type	Nickel Plated Brass
Contact Plating	Gold
Connector Gender	Female
LAN Category	Cat3
Ethernet Connector Type	RJ45

Key Features

This horizontal connector provides a single port with eight ways suitable for network connections.
Constructed with a copper alloy contact material plated with gold for reliable conductivity and corrosion resistance.
The connector supports a minimum operating temperature of -40°C and a maximum of 85°C.
It features a solder termination type and a tab-up modular jack design for easy PCB mounting.
The dimensions include a length of 16.14mm, width of 15.4mm, and depth of 16mm.
Rated for 500 mating cycles ensuring durability in frequent connect/disconnect use.
The shield is nickel plated brass to provide effective EMI protection and mechanical strength.

Product Description

Wurth Elektronik RJ45 WR-MJ Series RJ45 Connector Female model RJ45 is a PCB mount Ethernet connector designed for use with Cat3 LAN applications. This modular jack features a horizontal orientation with a single port and eight ways (8P8C), optimized for reliable data transmission in industrial and commercial electronic assemblies.

The connector utilizes high-quality copper alloy contacts plated with gold to ensure excellent electrical conductivity and resistance to corrosion. The nickel plated brass shield provides mechanical protection and effective electromagnetic interference (EMI) shielding, enhancing signal integrity.

Operating temperature ranges from -40°C to 85°C, supporting harsh industrial environments. The solder termination type facilitates secure PCB connections while the robust construction supports up to 500 mating cycles, making this connector durable for repeated use in telecommunications, Ethernet networks, and automation systems.

The compact dimensions, including 16.14mm length, 15.4mm width, and 16mm depth, allow easy integration into various PCB layouts without compromising space or performance. Its tab-up design ensures straightforward mounting and alignment on printed circuit boards.

This connector is free from hazardous area certification and specific standards approvals but meets RoHS compliance for environmental safety. Ideal for use in industrial, manufacturing, networking equipment, and telecom devices requiring reliable RJ45 Ethernet interfaces.

This connector provides a horizontal female modular jack suitable for PCB mounting. It offers Cat3 LAN category compatibility with one port and eight contact ways. Contact material is copper alloy plated with gold to enhance performance and durability.

The nickel plated brass shield offers robust EMI protection and mechanical shielding. Supports operating temperatures from -40°C up to +85°C for versatile applications. Solder termination ensures secure and stable PCB connections.

Compact physical dimensions facilitate efficient PCB integration. Rated for 500 mating cycles, supporting frequent connections and disconnections. Explore a wide range of Ethernet Connectors and electronic components on EnvMart to enhance your industrial and commercial projects with trusted brands like Wurth Elektronik.
