Vishay 940 nm Infrared LED PLCC-2 Surface Mount 5V 40mW Radiant Flux VSMB3940X01-GS08
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Dimensions | 3.5 x 2.8 x 1.75 mm |
| Model | VSMB3940X01-GS08 |
| Packaging | Tape & Reel |
| Mount Type | Surface |
| Beam angle | 120° |
| Number Of Leds | 1 |
| Package Type | PLCC 2 |
| Standards/Approvals | RoHS, Halogen Free, AEC-Q101, J-STD-020 |
| Number of Pins | 2 |
| Lens Shape | Round |
| Automotive Standard | AEC-Q101 |
| Maximum Supply Voltage | 5V |
| Peak Wavelength | 940nm |
| Radiant Flux | 40mW |
| LED Material | GaAlAs |
| Angle of half intensity | 60° |
| Radiant Intensity | 13mW/sr |
| ams OSRAM Chip LED 860 nm IR LED 0402 Surface packageBrand | ams OSRAM |
Key Features
- Compact PLCC-2 package measuring 3.5 x 2.8 x 1.75 mm.
- Peak wavelength of 940 nm for infrared applications.
- Radiant flux output of 40 mW with radiant intensity of 13 mW/sr.
- Surface mount type with a round lens shape and 120° beam angle.
- Operates with maximum supply voltage of 5V and low forward voltage.
- GaAlAs LED material ensures high reliability and radiant power.
- Suitable for IrDA data transmission, miniature light barriers, photointerrupters, and optical switches.
- Compliant with RoHS, Halogen Free, AEC-Q101, and J-STD-020 standards.
Product Description
Vishay VSMB3940X01-GS08 is a high-speed infrared emitting diode (IR LED) designed in a compact PLCC-2 surface mount package with dimensions 3.5 x 2.8 x 1.75 mm. It features a peak wavelength of 940 nm optimized for infrared applications requiring efficient light emission with low forward voltage.
This IR LED emits a radiant flux of 40 mW and provides a radiant intensity of 13 mW/sr with a wide 120° beam angle, making it suitable for diverse industrial and commercial applications such as IrDA compatible data transmission, miniature light barriers, photointerrupters, optical switches, shaft encoders, and various control and drive circuits.
The device uses GaAlAs semiconductor material ensuring high reliability and strong radiant power. It supports a maximum supply voltage of 5 V and comes with a round lens geometry for consistent beam shape. Manufactured to meet stringent industry standards including RoHS, Halogen Free directives, AEC-Q101 automotive standard, and J-STD-020 ensures quality and reliability in automotive and industrial environments.
The VSMB3940X01-GS08 is delivered in a tape & reel packaging format, facilitating automated assembly and production efficiency. Compact PLCC-2 SMT package for ease of PCB integration. Peak emission at 940 nm suitable for infrared applications.
High radiant flux and radiant intensity for strong IR output. Wide 120° beam angle for broad coverage. Compliance with automotive and environmental standards. Ideal for IR communication devices and optical sensing equipment.
Tape & reel packaging optimized for manufacturing throughput.
This IR LED is an excellent choice for industrial, laboratory, manufacturing, automotive, and commercial applications requiring reliable infrared light sources. Explore more related components and devices within EnvMart’s electronics catalog for comprehensive design and production solutions.
Explore more products in our Infrared LED category.
