Samtec Straight Through Hole PCB Header, 40 Contacts, 1.27 mm Pitch, 2 Row, Shrouded TFM-120-01-L-D-RE2-WT

Samtec TFM-120-01-L-D-RE2-WT is a Straight Through Hole PCB Header designed with 40 contacts and 1.27 mm pitch in 2 rows, featuring a shrouded construction.

The rugged Tiger Eye™ Terminal strip incorporates a multi-finger, BeCu contact system for exceptional reliability and endurance in high cycle surface mount or through-hole applications.

Its housing is made from Liquid Crystal Polymer, offering robust mechanical and thermal properties, with phosphor bronze contacts plated in gold for enhanced conductivity and corrosion resistance.

This connector supports a current of 3.2 amperes and voltage up to 250 volts, operating reliably between temperatures of -55°C and 125°C. The male contact gender and shrouded body allows for secure and blind mating suitable for complex PCB designs.

The header is compatible with vertical, right-angle, and horizontal orientations to enhance design flexibility, and termination is achieved through soldering via through-hole technology.

The connector system suits wire-to-board applications effectively. Special features such as screw down, weld tab, and solder nail options offer solutions for the most rugged requirements. Its durability and performance make it ideal for electronics manufacturing, industrial control systems, telecommunications, and other high-reliability applications.

The product is categorized under PCB Headers within Electronics Components, catering to specialized electronic and electrical manufacturing needs.

For comprehensive PCB and 3D mechanical designs, Samtec headers such as this model facilitate efficient mounting and connectivity, making them indispensable in modern electronics assembly.
