TE Connectivity PIDG Insulated Ring Terminal, M4 Stud Size, 26 AWG to 16 AWG Wire Size, Nylon Insulation 105°C 1-320551-4
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Colour | Red, White |
| THICKNESS | 0.79mm |
| Insulation | Insulated |
| Overall Length | 21.44mm |
| Contact Material | Copper |
| Series | PIDG |
| Maximum Operating Temperature | 105°C |
| Insulation Material | Nylon |
| Contact Plating | Tin |
| Minimum Wire Size mm² | 0.26mm² |
| Maximum Wire Size mm² | 1.65mm² |
| Minimum Wire Size AWG | 26AWG |
| Maximum Wire Size AWG | 16AWG |
| Outer Ring Diameter | 7.92mm |
| Inner Ring Diameter | 4.34mm |
| Stud Size | M4 |
Key Features
- Constructed with high conductivity copper for excellent electrical performance.
- Features nylon insulation rated for up to 105°C to ensure safe and durable use.
- Serrated wire barrel enhances maximum contact and tensile strength after crimping.
- Colour-coded red and white nylon sleeves for quick wire size identification.
- Funnelled entry design allows easy wire insertion to prevent fraying during crimping.
- Suitable for instruments, control panels, power supplies, aerospace, transportation, and industrial machinery.
- Pre-insulated design helps improve wiring speed and reliability in demanding environments.
Product Description
TE Connectivity 1-320551-4 PIDG Insulated Ring Terminal is a precision-engineered electrical connector designed for wiring applications requiring secure attachment to M4 studs. The terminal supports wire sizes ranging from 26 AWG to 16 AWG and is insulated with durable nylon material rated for a maximum operating temperature of 105°C. This ensures both safety and longevity in various electrical circuits.
The body is made from high conductivity copper with tin plating to provide superior electrical contact and corrosion resistance. Inside the barrel, serrations improve tensile strength and contact reliability after crimping. The copper sleeve around the wire barrel enhances insulation support and prevents wire strand fraying.
The terminal's outer nylon sleeve is colour coded red and white for easy wire size identification and tooling compatibility. The funnelled wire entry facilitates fast wire insertion, making it suitable for high-volume production environments.
PIDG ring terminals from TE Connectivity are ideal for use in instruments and control systems, lighting, power supplies, panel boxes, motors, aerospace, transportation, and lifting equipment applications. Their robust design ensures dependable connections in harsh industrial and commercial environments.
The 1-320551-4 model supports a wide range of wiring tasks with its reliable construction, ensuring consistent performance for electrical and electronic components. Constructed with high conductivity copper for excellent electrical performance.
Features nylon insulation rated for up to 105°C to ensure safe and durable use. Serrated wire barrel enhances maximum contact and tensile strength after crimping. Colour-coded red and white nylon sleeves for quick wire size identification.
Funnelled entry design allows easy wire insertion to prevent fraying during crimping. Suitable for instruments, control panels, power supplies, aerospace, transportation, and industrial machinery. Pre-insulated design helps improve wiring speed and reliability in demanding environments.
Explore more TE Connectivity products and other Ring Terminals at EnvMart for comprehensive electrical connector solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this insulated ring terminal is 105°C.
This terminal supports wire sizes ranging from 26 AWG to 16 AWG.
The stud size for this model is M4.
The terminal is constructed from high conductivity copper with tin plating for enhanced electrical contact and corrosion resistance, and it features nylon insulation.
The overall length of this terminal is 21.44 mm, with an outer ring diameter of 7.92 mm and an inner ring diameter of 4.34 mm.
The serrated wire barrel enhances maximum contact and tensile strength after crimping, improving connection reliability.
The outer nylon sleeve is color-coded red and white for quick wire size identification.
This terminal is suitable for use in instruments, control panels, power supplies, aerospace, transportation, and industrial machinery.
The thickness of the nylon insulation is 0.79 mm.
The pre-insulated design helps improve wiring speed and reliability in demanding environments.
The minimum wire size is 0.26 mm² and the maximum wire size is 1.65 mm².
This terminal is manufactured in India.
