Texas Instruments Current Sensing Amplifier Single 6-Pin SC-70 2.7V-26V INA210AIDCKT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 0.9mm |
| Length | 2mm |
| Model | INA210AIDCKT |
| Mount Type | Surface |
| Series | INA210 |
| Maximum Operating Temperature | 125°C |
| Package Type | SC-70 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 6 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 26V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 100μA |
| GBP - Gain Bandwidth Product | 14kHz |
| CMRR - Common Mode Rejection Ratio | 105dB |
Key Features
- Operates with a single power supply from 2.7V to 26V.
- Provides a high common mode rejection ratio (CMRR) of 105 dB.
- Draws a low supply current of 100 μA for energy-efficient operation.
- Features a gain bandwidth product (GBP) of 14 kHz suitable for various sensing applications.
- Designed to meet automotive standard AEC-Q100 for reliability and durability.
- Compact surface mount SC-70 package measuring 2 mm length and 0.9 mm height.
- Operating temperature range from -40°C to 125°C for robust performance in harsh environments.
- Single channel amplifier ideal for real-time system protection and feedback control.
Product Description
Texas Instruments INA210AIDCKT Current Sensing Amplifier operates on a single power supply voltage ranging from 2.7V to 26V, making it versatile for a broad range of industrial, automotive, and electronic applications. It supports precise current and power measurement through a voltage output proportional to the voltage drop across a low-value resistor on the power rail.
The device boasts a high common mode rejection ratio (CMRR) of 105 dB, which ensures accurate signal amplification even in noisy environments. With a gain bandwidth product (GBP) of 14 kHz, it performs well within real-time system monitoring and feedback control systems with low power draw at 100 μA.
This current sensing amplifier is packaged in a compact 6-pin SC-70 surface mount package with dimensions of 2 mm length and 0.9 mm height, facilitating integration into compact PCB designs. It features a robust operating temperature range from -40°C up to 125°C, satisfying automotive standard AEC-Q100 for high reliability in automotive and industrial sectors.
Applications include system protection, feedback control, high-accuracy monitoring, and power management in industrial, automotive, laboratory, and electronic manufacturing environments.
Operates with a single supply voltage from 2.7V to 26V. Achieves a common mode rejection ratio (CMRR) of 105 dB for noise reduction. Consumes low supply current of 100 μA for efficient performance. Gain bandwidth product of 14 kHz conducive for precision sensing.
Automotive standard AEC-Q100 qualified for reliability. Compact 6-pin SC-70 surface mount package. Wide operating temperature range from -40°C to 125°C. Single channel operation ideal for current measurement.
This Texas Instruments INA210AIDCKT model represents a reliable, efficient solution for current sensing amplifier needs in diverse applications. Explore more Current Sensing Amplifiers from Texas Instruments in the EnvMart catalog for comprehensive industrial and laboratory instrumentation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This current sensing amplifier operates with a single power supply voltage ranging from 2.7V to 26V.
It achieves a high common mode rejection ratio (CMRR) of 105 dB, which helps in reducing noise during signal amplification.
The device draws a low supply current of 100 μA, making it energy-efficient.
The compact SC-70 package measures 2 mm in length and 0.9 mm in height, facilitating integration into small PCB designs.
This model is a single channel amplifier, designed for precise current measurement.
Yes, it is designed to meet the automotive standard AEC-Q100, ensuring reliability in automotive environments.
It features a surface mount design, allowing for easy integration into various applications.
This current sensing amplifier is suitable for system protection, feedback control, and high-accuracy monitoring in industrial and automotive applications.
This model has a pin count of 6, making it compact and easy to integrate into circuit designs.
The INA210AIDCKT is manufactured in India.
