STMicroelectronics 1-Element Bi-Directional TVS Diode 600 W, Surface Mount DO-214 Package SM6T22CA

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics 1-Element Bi-Directional TVS Diode 600 W, Surface Mount DO-214 Package SM6T22CA

Name: STMicroelectronics 1-Element Bi-Directional TVS Diode 600 W, Surface Mount DO-214 Package SM6T22CA
Brand: STMicroelectronics
SKU: 98456
Price: 0.17 USD
Availability: InStock



Category TVS Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	2.45mm
Length	4.6mm
Model	SM6T22CA
Width	3.95mm
Mount Type	Surface
Series	SM6T
Maximum Operating Temperature	150°C
Package Type	DO-214
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	39.3V
Diode Configuration	Single
Direction Type	Bi-Directional
Minimum Breakdown Voltage Vbr	20.9V
Maximum Reverse Stand-off Voltage Vwm	18.8V
Peak Pulse Power Dissipation Pppm	600W
Test Current It	1mA
Maximum Peak Pulse Current Ippm	102A
Maximum Reverse Leakage Current	200nA

Key Features

The diode features a single-element configuration designed for transient voltage suppression.
It supports bi-directional operation suitable for protecting circuits against voltage spikes.
Minimum breakdown voltage is 20.9 V with a maximum reverse stand-off voltage of 18.8 V.
The component has a maximum peak pulse current of 102 A and clamps voltage at 39.3 V.
Temperature operating range extends from -55°C to 150°C for reliable performance.
Compact dimensions include height 2.45 mm, length 4.6 mm, and width 3.95 mm.
Designed to surface mount onto PCBs, enhancing efficient assembly in electronics manufacturing.

Product Description

STMicroelectronics SM6T22CA is a robust 1-element bi-directional Transient Voltage Suppressor (TVS) diode designed to protect electronic circuits from voltage spikes and transient surges. Featuring a peak pulse power dissipation rating of 600 W, this diode provides efficient suppression of transient voltages in sensitive semiconductor devices.

Housed in a compact DO-214 surface mount package, the SM6T22CA diode is optimized for surface mount technology (SMT) assembly, supporting automated production processes. The bi-directional diode configuration enables protection in both directions, making it versatile for various electronic circuit applications.

Key electrical characteristics include a minimum breakdown voltage of 20.9 V, maximum reverse stand-off voltage of 18.8 V, and a high peak pulse current capability of 102 A. The diode clamps voltage at 39.3 V under transient conditions to safeguard connected components effectively.

Measuring 2.45 mm in height, 4.6 mm in length, and 3.95 mm wide, this component offers a small footprint suitable for space-constrained designs. It operates reliably within a wide temperature range from -55°C to 150°C, ensuring stable functionality under challenging environmental conditions.

This TVS Diode is ideal for use in industrial electronics, telecommunications, power supplies, automotive electronics (non-automotive standard), and consumer electronic devices requiring transient voltage protection. It enhances circuit protection to prevent damage from voltage transients caused by electrostatic discharge, lightning, or inductive load switching.

The diode's single element and bi-directional nature make it suitable for protecting AC and DC circuits. The surface mount DO-214 package facilitates SMT assembly for efficient manufacturing. High peak pulse power rating of 600 W supports robust transient event absorption.

Wide operating temperature range allows deployment in diverse industrial environments. Compact size facilitates integration into dense PCB layouts. Explore more STMicroelectronics semiconductor products and find compatible components for your electronics projects and industrial applications at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The SM6T22CA diode has a peak pulse power dissipation rating of 600 W, allowing it to efficiently suppress transient voltages.

The minimum breakdown voltage for the SM6T22CA is 20.9 V, which is essential for its operation in protecting circuits from voltage spikes.

The maximum reverse stand-off voltage of the SM6T22CA is 18.8 V, ensuring it can withstand voltage without conducting.

The clamping voltage for this diode is 39.3 V, which helps protect connected components during transient events.

The SM6T22CA can handle a maximum peak pulse current of 102 A, making it suitable for high-energy transients.

This diode measures 2.45 mm in height, 4.6 mm in length, and 3.95 mm in width, making it compact for PCB applications.

The operating temperature range for the SM6T22CA is from -55°C to 150°C, allowing it to function reliably in various environments.

This model is designed for surface mount technology (SMT), facilitating efficient assembly on PCBs.

The SM6T22CA features a single-element configuration that supports bi-directional operation for circuit protection.

This diode is suitable for use in industrial electronics, telecommunications, power supplies, automotive electronics, and consumer devices requiring transient voltage protection.
