TE Connectivity MTA-156 Series Right Angle Through Hole Pin Header, 4 Contacts, 3.96 mm Pitch, 1 Row, Unshrouded 640387-4

TE Connectivity 640387-4 MTA-156 Series right angle through hole pin header is a high-quality connector designed for wire-to-board applications. Featuring 4 contacts with a pitch of 3.96 mm and a single row, this unshrouded header provides reliable mass termination of wires when used with compatible IDC connectors. Its glass filled polyester housing offers excellent mechanical strength and high temperature endurance, making it suitable for industrial and automotive applications.

The right angle orientation allows for flexible PCB designs, particularly in areas where space constraints necessitate a horizontal connection. The friction lock mechanism ensures a secure and stable mating with IDC connectors, preventing accidental disconnection during operation.

This MTA-156 header is rated for a maximum current of 7A and can withstand voltages up to 600V, suitable for various electrical and electronic systems. Contact surfaces are plated with tin over copper alloy to provide corrosion resistance and ensure good electrical conductivity.

Operating temperatures range from -55°C to 105°C, making the header viable for harsh environmental conditions. The termination is solder type, and the male contact pins have a tail length of 3.18 mm and a mating pin length of 10.16 mm, ensuring compatibility and durability in connections.

The MTA-156 system is ideal for cost-effective mass wire termination in automotive body and chassis systems, safety and security applications, as well as in consumer electronics such as desktop PCs, notebooks, servers, and storage devices. This connector helps reduce assembly time by using insulation displacement contact technology and production hand tooling.

Provides a reliable wire-to-board connection for mass wire termination. Right angle orientation suitable for various PCB layouts. Uses glass filled polyester housing for durability and thermal stability. Friction lock mechanism ensures secure mating connection with IDC connectors.

Rated for 7A current and 600V voltage applications. Contact plating with tin for corrosion resistance and conductivity. Operating temperature range from -55°C to 105°C. Mating pin length of 10.16 mm supports secure connection.

Compatible with 26 AWG to 18 AWG wire sizes for versatile applications. Through hole mounting enables sturdy PCB installation. Explore more PCB header connectors and electronic components at EnvMart to find the right components for your design and manufacturing needs.
