Preci-Dip 2.54 mm Pitch Vertical 28 Way Surface Turned Pin Open Frame DIL Socket 1A 110-87-328-41-105101

Preci-Dip 110-87-328-41-105101 is a precision-engineered 28-way Dual-In-Line (DIL) open frame socket with a 2.54 mm pitch designed for vertical orientation and surface mounting on printed circuit boards (PCBs). This socket is designed for applications where reliable IC connections are required in electronics manufacturing, testing, and repair.

The socket supports a current rating of 1 ampere and operates at voltage levels up to 150V AC, making it suitable for various industrial and laboratory electronic equipment. Its turned pin type contact ensures secure insertion of ICs, backed by gold and tin plating for corrosion resistance and excellent electrical conductivity.

Manufactured with a fiberglass reinforced polyethylene terephthalate housing, this component provides robust mechanical strength and insulation. The brass and beryllium copper alloy contacts offer durable electrical performance required in demanding environments.

Operating temperature range from -55°C to 125°C enables the socket to function reliably in diverse climatic and industrial settings. The solder termination, compatible with reflow and vapor phase soldering, facilitates strong and reliable mounting to PCBs.

The open frame design paired with a 7.62 mm row width and dimensions of 35.5 mm length, 10.1 mm width, and 2.8 mm depth make this socket versatile for space-efficient PCB layouts. Its Swiss origin assures high standards of quality and precision engineering.

The socket supports a current rating of 1A and voltage up to 150V AC. Features a 2.54 mm pitch with 28 contacts for versatile IC compatibility. Turned pin type with gold and tin contact plating ensures reliability. Robust Philips fiberglass reinforced housing for durability and insulation.

Operates reliably in temperature range -55°C to 125°C. Contacts made of brass and beryllium copper alloy for conductivity. Solder termination supports advanced reflow soldering techniques. Open frame design with 7.62 mm row width suitable for diverse PCBs.

Manufactured in Switzerland adhering to high-quality standards.

This product is ideal for use in industrial electronics manufacturing, laboratory test equipment, commercial electronic devices, and electronic prototyping environments. It enhances production efficiency and provides reliable IC socket solutions.
