Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 7 Contact, 2.54 mm Pitch, 1 Row 811-S1-007-10-017101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Model | 811-S1-007-10-017101 |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 811 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 7 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Features spring-loaded brass contacts plated with gold for reliable electrical connection.
- Current rating of 3.5A suitable for moderate power applications.
- Operating temperature range from -55°C to 125°C allows for demanding environments.
- Housing made from fibreglass reinforced polyethylene terephthalate offers durability and insulation.
- Compact 2.54 mm pitch with straight orientation and shrouded design for protection.
- Supports solder termination type ensuring secure mounting on PCBs.
- Manufactured in Switzerland ensuring high quality and precision engineering.
Product Description
Preci-Dip 811-S1-007-10-017101 is a high-quality spring loaded connector designed for through hole PCB mounting. With 7 gold-plated brass contacts arranged in a single row with a 2.54 mm pitch, this shrouded connector offers excellent electrical performance and mechanical reliability.
The connector features spring loaded contacts which maintain low and stable resistance, even during vibrations or movement, making it ideal for industrial, electronics manufacturing, laboratory equipment, and automation applications requiring multi-point connections with high durability and consistent electrical contact.
Its housing is made from fibreglass reinforced polyethylene terephthalate, providing robust insulation and mechanical strength suitable for harsh environmental conditions. The connector supports a maximum rated current of 3.5A and voltage of 150V, operating reliably between temperatures of -55°C to 125°C.
The plunger stroke length of 1.4 mm in these connectors enhances flexibility to absorb mechanical tolerances while the plastic body height is 4 mm, ensuring compact integration in PCB layouts.
This model is manufactured in Switzerland and conforms to UL 94V-0 standard ensuring flame retardant material properties. Its male contact gender and solder termination type ensure compatibility with a wide range of PCB designs requiring durable and high-performance connections.
Spring loaded brass contacts with gold plating for low resistance. Through hole mounted, shrouded for protection. 7 contacts, 1 row, straight orientation, 2.54 mm pitch. Operating temperature range from -55°C to 125°C. Rated for 3.5 Amperes current and 150 Volts voltage.
Fibreglass reinforced polyethylene terephthalate housing. Flame retardant UL 94V-0 compliant material. Manufactured in Switzerland for high reliability and quality.
This spring loaded connector is ideal for demanding electronics applications in industrial automation, laboratories, electrical measurements, and control equipment. Its sturdy design ensures a stable, low resistance connection that resists vibration-induced failures, suitable for consistent signal and power transmission. Explore a broad portfolio of connectors and PCB components at EnvMart for reliable industrial-grade solutions.
Explore more products in our PCB Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this connector is 3.5A, suitable for moderate power applications.
This model operates reliably within a temperature range of -55°C to 125°C, making it suitable for demanding environments.
It uses a solder termination type, ensuring secure mounting on PCBs.
This connector features 7 contacts arranged in a single row.
The pitch of this through hole connector is 2.54 mm, allowing for compact integration in PCB layouts.
The housing is made from fibreglass reinforced polyethylene terephthalate, providing durability and insulation.
This connector is shrouded, which provides additional protection for the contacts.
The voltage rating for this connector is 150V, suitable for various applications.
The contacts are made of brass and are plated with gold for reliable electrical connections.
This connector is manufactured in Switzerland, ensuring high quality and precision engineering.
This connector is suitable for industrial automation, laboratory equipment, and electrical measurements, among other applications.
The plastic body height of this connector is 4 mm, allowing for compact integration in PCB designs.
