ABB 6-Pole Screw Mount Switch Disconnector with IP65 Rating, Handle Red Yellow, Series OTE, Model



Category Switch Disconnector Brand ABB Condition New

Specifications

Country of Origin	Finland
Brand	ABB
Length	85mm
Model	IP65
Depth	85mm
IP Rating	IP65
Width	130mm
Mount Type	Screw
Series	OTE
Minimum Operating Temperature	0°C
Switching Current	0A
Terminal type	Screw Clamp
Handle Colour	Red, Yellow
Number of Poles	6
Standards/Approvals	RoHS

Key Features

Equipped with a rigid glass-reinforced polycarbonate enclosure for durability.
IP65 rated enclosure provides protection against low-pressure water jets.
Handle colors are red and yellow with three padlock capability for enhanced safety.
Designed for a 5-wire system with fixed neutral and PE terminals.
Includes a metal EMC protection plate eliminating the need for EMC glands.
Switch supports up to 2 auxiliary contacts (2NO/1NC) for expanded functionality.
Suitable for switching current of 0A and operational voltage up to 750V.
Cable entries are threaded with knock out holes for multiple cable configurations.

Product Description

ABB model 1SCA022681R1250 is a 6-Pole Screw Mount Switch Disconnector in the OTE series designed for robust isolation and switching applications. Featuring a rigid glass-reinforced polycarbonate enclosure, it offers UV protection and IP65 rating which ensures resistance to low-pressure water jets, making it suitable for both indoor and outdoor industrial environments.

The switch disconnector supports a 5-wire system setup including a fixed neutral terminal and PE terminal. It allows the connection of three padlocks on the handle for enhanced security and lockout-tagout procedures. The handle itself is dual-colored red and yellow for clear identification.

This model comes with a metal plate for EMC protection connected through cable shield clamps, removing the need for EMC glands. Cable entries are thread-equipped with knockout holes allowing parallel and control cables from both top and bottom mounting points, enhancing installation flexibility.

It has a switching current rating of 0A and is rated for operational voltages up to 750V. Up to two auxiliary contacts (2NO/1NC) may be mounted for signaling or control applications. Its compact dimensions of 85 mm length, 130 mm width, and 85 mm depth enable convenient incorporation into control panels and switchgear assemblies.

The enclosure complies with RoHS regulations ensuring environmental friendliness. Manufactured in Finland, this product guarantees quality and reliability for industrial, electrical automation, and facility management use cases.

Equipped with a rigid glass-reinforced polycarbonate enclosure for durability. IP65 rated enclosure provides protection against low-pressure water jets. Handle colors are red and yellow with three padlock capability for enhanced safety.

Designed for a 5-wire system with fixed neutral and PE terminals. Includes a metal EMC protection plate eliminating the need for EMC glands. Switch supports up to 2 auxiliary contacts (2NO/1NC) for expanded functionality.

Suitable for switching current of 0A and operational voltage up to 750V. Cable entries are threaded with knock out holes for multiple cable configurations. Compact dimensions: length 85 mm, width 130 mm, depth 85 mm. Meets RoHS standards and is manufactured in Finland.
