Preci-Dip 28 Way 2.54 mm Pitch Vertical Surface Turned Pin Open Frame DIL Socket 1A 110-87-628-41-105161

Preci-Dip 110-87-628-41-105161 is a precision-engineered 28 Way Dual In-Line (DIL) Socket designed with a 2.54 mm pitch and vertical orientation for surface mount PCB applications. This open frame DIL socket provides reliable connections with its turned pin design constructed from brass and beryllium copper alloy, ensuring excellent conductivity and mechanical stability.

Featuring solder termination type with gull wing terminations, this socket supports strong solder joints vital for high-performance printed circuit boards. The sleeves are made from tin-plated brass with four finger gold flash contact clips to further enhance signal integrity and reliability. The housing is fabricated using fibreglass reinforced polyethylene terephthalate, offering high durability, mechanical strength, and resistance to environmental factors.

This socket is rated for a current of 1 amp and voltage ranging from 100 to 150 volts AC, making it suitable for various industrial and electronic design applications. Its operational temperature range spans from -55°C minimum to 125°C maximum, allowing robust performance across harsh environments. The compact form factor measures 35.5 mm in length, 17.7 mm in width, and 2.8 mm in depth, facilitating space-efficient PCB layouts.

The product complies with UL 94V-0 standards for flame retardant materials, ensuring safe use in electronic assemblies. Manufactured in Switzerland, this Preci-Dip model guarantees superior quality and precision expected in advanced electronics manufacturing.

The open frame design permits easy visual inspection and soldering access. Materials selected to ensure long-lasting electrical and mechanical performance. Ideal for industrial electronics, laboratory devices, communication equipment, and manufacturing systems.

Supports surface mounting processes including reflow and vapor phase soldering. Solder termination type promotes secure and reliable PCB attachment. Wide temperature range suitable for laboratory testing and commercial devices.

Compact and vertical orientation optimizes circuit board density.

Designed specifically for experienced engineers and technicians requiring dependable DIL sockets, this Preci-Dip component supports a wide range of applications including test equipment, industrial controls, and other precision electronics. EnvMart offers this high-quality DIL Socket with comprehensive specifications to aid informed procurement decisions.
