Nexperia Transistor PNP 100 mA, 45 V, 3-Pin SOT-883 Surface Mount BC857BM,315

Nexperia BC857BM,315 is a PNP bipolar transistor designed for general-purpose switching and amplification applications. It features a maximum DC collector current of 100 mA and maximum collector-emitter voltage of 45 V housed in the ultra-compact 3-pin SOT-883 (SC-101) leadless plastic package measuring just 1.2 mm by 0.62 mm by 0.47 mm.

This transistor supports a maximum power dissipation of 430 mW and a transition frequency of up to 100 MHz, making it ideal for low to medium frequency AC applications such as mobile communications, digital cameras, PDAs, and PCMCIA cards. It is RoHS compliant and designed to optimize board space with its leadless package of approximately 1.3 x 0.9 mm footprint.

The device operates reliably over a wide temperature range from -65°C to 150°C. It features a high current gain (hFE) minimum of 125 and is suitable for surface mount assembly processes. This transistor series offers a broad range of small-signal bipolar devices with various package options, delivering excellent compactness and performance for demanding industrial and commercial electronics.

The transistor provides a maximum collector base voltage (VCBO) of 50 V and maximum emitter base voltage (VEBO) of 5 V. Its small size and efficient power dissipation allow usage in compact designs and high-density circuit boards.

This transistor is widely applicable across electronics manufacturing, laboratory testing, industrial equipment, and consumer electronics sectors. Its surface mount configuration supports automated assembly and higher reliability in electronic circuits.

For additional technical documents, 3D models, schematics, and footprints, users are encouraged to utilize design resources compatible with this transistor model. Explore more Bipolar Transistors and related semiconductor products to find complementary components on EnvMart's Electronics & Electricals section.
