Nexperia Surface Mount Schottky Diode 40 V 1.4 A 2-Pin SOD-123W PMEG4010ETR,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 2.8mm |
| Model | PMEG4010ETR,115 |
| Width | 1.9mm |
| Mount Type | Surface |
| Series | PMEG4010ETR |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-123W |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1.4A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 30mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 490mV |
| Peak Reverse Recovery Time trr | 4.4ns |
| Average forward current | IF(AV) ≤ 1 A |
| Reverse voltage | VR ≤ 40 V |
Key Features
- This diode is encapsulated in a SOD-123W package suitable for surface mounting.
- The device features a low forward voltage drop of 490 mV, enhancing efficiency.
- It is rated for a peak non-repetitive forward surge current of 50 A.
- Designed to operate reliably within temperatures ranging from -55°C to 175°C.
- The diode has a fast peak reverse recovery time of 4.4 ns, ideal for high-frequency switching applications.
- Compliance with automotive standard AEC-Q101 ensures robustness for automotive environments.
- Small dimensions with length 2.8 mm, width 1.9 mm, and height 1.1 mm facilitate compact PCB layouts.
Product Description
Nexperia PMEG4010ETR,115 is a high-performance Schottky barrier diode designed for low voltage-drop rectification in compact surface-mount packages.
This 2-pin diode is built on planar maximum efficiency general application (MEGA) technology and encapsulated in a SOD-123W plastic package. It supports a maximum continuous forward current (If) of 1.4 A and can withstand peak reverse repetitive voltage (Vrrm) of 40 V, making it suitable for medium-power applications.
The diode features a low forward voltage of 490 mV and a peak reverse recovery time (trr) of 4.4 ns, enabling high efficiency and fast switching essential for power supply circuits, battery-powered devices, and automotive systems.
Operating temperatures range from -55°C to 175°C, which allows usage in harsh industrial and automotive environments. The device complies with the automotive standard AEC-Q101, assuring quality and reliability in automotive electronics.
Its compact dimensions (2.8 mm length, 1.9 mm width, and 1.1 mm height) and low profile contribute to space-saving on printed circuit boards, making it ideal for densely packed electronic assemblies.
This diode effectively extends battery life by reducing forward voltage losses. Clip-bonding technology enhances power capability and thermal performance. The integrated guard ring provides stress protection against voltage spikes.
Typical applications include power management circuits, DC/DC converters, and rectification in power supplies. Its robust design suits use in industrial, automotive, and consumer electronics. Enables efficient switching in high-frequency power conversion systems.
Small size supports miniaturization trends in modern electronics manufacturing. Overall, the Nexperia PMEG4010ETR,115 diode offers a reliable, efficient, and compact solution for various electronic design needs requiring Schottky barrier diodes.
Explore more Schottky Diodes and rectifiers within EnvMart's extensive semiconductor portfolio to find the ideal component for your application.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current (If) of this Schottky diode is 1.4 A.
The diode is rated for a peak reverse repetitive voltage (Vrrm) of 40 V.
This model has dimensions of 2.8 mm in length, 1.9 mm in width, and 1.1 mm in height.
The diode features a low forward voltage drop of 490 mV.
It can withstand a peak non-repetitive forward surge current of 50 A.
The operating temperature range is from -55°C to 175°C.
The peak reverse recovery time (trr) is 4.4 ns, making it suitable for high-frequency applications.
It is encapsulated in a SOD-123W package, which is suitable for surface mounting.
This model complies with the automotive standard AEC-Q101, ensuring reliability in automotive applications.
The average forward current (IF(AV)) is rated at 1 A or less.
This diode is a Schottky rectifier, designed for low voltage-drop rectification.
Typical applications include power management circuits, DC/DC converters, and rectification in power supplies.
