Power Integrations High Side Off Liner Power Switch IC 8-Pin DIP-B 2.6W 375mA LNK362PN

Free Delivery in India | Lowest Global Shipping Charges

Power Integrations High Side Off Liner Power Switch IC 8-Pin DIP-B 2.6W 375mA LNK362PN

Name: Power Integrations High Side Off Liner Power Switch IC 8-Pin DIP-B 2.6W 375mA LNK362PN
Brand: Power Integrations
SKU: 213708
Price: 0.82 USD
Availability: InStock



Category Power Switch ICs Brand Power Integrations Condition New

Specifications

Country of Origin	India
Brand	Power Integrations
Height	3.68mm
Length	9.83mm
Model	LNK362PN
Width	6.6mm
Mount Type	Through Hole
Number of inputs	1
Series	LNK362
Power Rating	2.6W
Maximum Operating Temperature	150°C
Package Type	DIP-B
Minimum Operating Temperature	-40°C
Operating Current	375mA
Number of outputs	5
Pin Count	8
Switch On Resistance RdsOn	88Ω

Key Features

Incorporates a 700 V power MOSFET integrated monolithic IC.
Supported by a high-voltage switched current source and frequency jittering to reduce EMI.
Offers accurate hysteretic thermal shutdown and auto-restart for fault protection.
Through Hole mount type with DIP-B package ensures easy PCB integration.
Operates reliably at temperatures from -40°C to 150°C.
Power rating of 2.6W and operating current of 375mA suitable for varied power needs.
Features cycle-by-cycle current limiting for enhanced safety and reliability.
Ideal for power supply design, industrial control, and switching applications.

Product Description

Power Integrations LNK362PN High Side Off Liner Power Switch IC 8-Pin DIP-B is a monolithic semiconductor device designed to provide efficient and reliable power switching solutions. It integrates a 700 V power MOSFET, oscillator, and a simple ON/OFF control scheme along with advanced features like frequency jittering and cycle-by-cycle current limiting. This device is particularly useful in applications requiring robust power management with protection features.

The LNK362PN operates over a wide temperature range from -40°C to 150°C and supports an operating current of 375mA, with a power rating of 2.6W. Its through-hole mount and DIP-B 8-pin package facilitate easy handling and integration onto PCB designs.

Its fully integrated auto-restart for short circuit and open loop protection helps reduce power delivery by 95% under fault conditions, increasing system reliability. Frequency jittering greatly reduces electromagnetic interference, making it suitable for industrial and commercial power supplies.

The device meets high voltage creepage requirements between the DRAIN pin and all other pins, ensuring electrical safety and compliance in demanding operational environments. Dimensions of 9.83mm length, 6.6mm width, and 3.68mm height make the LNK362PN compact enough for both industrial, laboratory, and commercial electronics use cases.

Incorporates 700 V power MOSFET and oscillator on a monolithic IC. Supports simple ON/OFF control with high-voltage current sources. Frequency jittering reduces EMI and improves performance. Cycle-by-cycle current limiting enhances safety.

Fully integrated auto-restart protects against fault conditions. Through Hole mount type with DIP-B eight-pin package. Operating current: 375mA and power rating: 2.6W. Temperature range: -40°C to 150°C for wide environmental operation.

This power switch IC is ideally suited for switching power supplies, industrial controllers, and power management circuits. Its robust protection features and ease of integration make it an essential component for reliable power system designs.
