Taiwan Semiconductor Operational Amplifier 2-Channel 1 MHz 8-Pin PDIP 5-32V TS358CD C3G
Specifications
| Country of Origin | India |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 4.45mm |
| Length | 9.32mm |
| Model | TS358CD C3G |
| Width | 6.48mm |
| Mount Type | Through Hole |
| Series | TS358 |
| Output Current | 40mA |
| Maximum Operating Temperature | 70°C |
| Package Type | PDIP |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 32V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | -500 nA |
| Vos - Input Offset Voltage | 7 mV |
| Slew Rate | 0.4V/μs |
| Input Offset Current | 150 nA |
Key Features
- Operates with a gain bandwidth product of 1 MHz for efficient signal amplification.
- Dual-channel design supporting multiple analog input signals.
- Compatible with through-hole mount technology and housed in an 8-pin PDIP package.
- Operating voltage ranges from 5 volts minimum up to 32 volts maximum.
- Input offset voltage measured at 7 millivolts, ensuring precise amplification.
- Slew rate of 0.4 volts per microsecond to manage signal change rates effectively.
- Output current capability up to 40 milliamperes for driving loads.
- Operating temperature span from 0°C to a maximum of 70°C for standard industrial environments.
Product Description
Taiwan Semiconductor TS358CD C3G is a dual-channel operational amplifier designed for general-purpose analog signal processing with a gain bandwidth product of 1 MHz. Encased in an 8-pin PDIP package and compatible with through-hole mounting, this device operates efficiently over a voltage range of 5 to 32 volts, making it suitable for a wide range of electronics applications.
This operational amplifier offers a low input offset voltage of 7 millivolts and an input bias current of -500 nanoamperes, providing accuracy and stability in sensitive analog circuits. Its slew rate of 0.4 volts per microsecond enables it to handle moderate frequency signals without distortion.
With an output current capacity of up to 40 milliamperes, the TS358CD C3G can effectively drive various downstream loads. The component is rated for operation within 0°C to 70°C, accommodating typical industrial and commercial environment temperature ranges.
The compact package dimensions of 9.32 mm length, 6.48 mm width, and 4.45 mm height allow for space-efficient PCB layouts. The PDIP package type facilitates easy prototyping and assembly.
Operates with a gain bandwidth product of 1 MHz for efficient signal amplification. Dual-channel design supporting multiple analog input signals. Compatible with through-hole mount technology and housed in an 8-pin PDIP package.
Operating voltage ranges from 5 volts minimum up to 32 volts maximum. Input offset voltage measured at 7 millivolts, ensuring precise amplification. Slew rate of 0.4 volts per microsecond to manage signal change rates effectively.
Output current capability up to 40 milliamperes for driving loads. Operating temperature span from 0°C to a maximum of 70°C for standard industrial environments. Compact dimensions for efficient PCB space utilization.
This dual operational amplifier is ideal for industrial, electronic component manufacturing, HVAC, instrumentation, and general-purpose analog signal conditioning applications. Taiwan Semiconductor delivers reliable semiconductor solutions compatible with numerous electronic designs. Explore more Amplifiers and Operational Amplifiers in EnvMart for extensive product selection and detailed technical specifications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TS358CD C3G has a gain bandwidth product of 1 MHz, which allows for efficient signal amplification.
It can provide an output current of up to 40 milliamperes, suitable for driving various loads.
The input offset voltage is measured at 7 millivolts, ensuring precise amplification in sensitive circuits.
The dimensions are 9.32 mm in length, 6.48 mm in width, and 4.45 mm in height, allowing for efficient PCB layouts.
The slew rate is 0.4 volts per microsecond, enabling it to manage moderate frequency signals effectively.
It operates within a temperature range from 0°C to a maximum of 70°C, suitable for standard industrial environments.
This operational amplifier features a dual-channel design, supporting multiple analog input signals.
It is compatible with through-hole mounting technology, housed in an 8-pin PDIP package.
The input bias current is -500 nanoamperes, which contributes to its accuracy in sensitive applications.
This operational amplifier is ideal for industrial, electronic component manufacturing, HVAC, instrumentation, and general-purpose analog signal conditioning.
The input offset current is 150 nanoamperes, which helps maintain stability in analog circuits.
