Molex Mini-Latch Series Straight Through Hole Pin Header, 13 Contacts, 2.5 mm Pitch, 1 Row, Unshrouded 22-04-1131
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Latch |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 13 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a 2.5 mm pitch for precise PCB compatibility.
- Includes 13 male contacts arranged in a single row.
- Constructed with nylon housing and brass contacts with tin plating.
- Supports a current rating of 3A and voltage up to 250V.
- Designed for through hole mounting for reliable mechanical strength.
- Operates between -40°C to 105°C for robust performance.
- Unshrouded design facilitates easy solder termination.
- Suitable for wire-to-board connector systems in various electronic applications.
Product Description
Molex 22-04-1131 is a Mini-Latch Series Straight Through Hole Pin Header designed for use in a wide range of electronic and electrical applications. It features 13 male contacts arranged in a single row with a 2.5 mm pitch, making it ideal for wire-to-board connections.
The product housing is made of durable nylon material while the contacts are brass plated with tin for excellent conductivity and corrosion resistance. This pin header supports a continuous current of up to 3A and a maximum operating voltage of 250V, suitable for industrial and commercial use cases.
Engineered with through hole mounting, it offers secure mechanical retention on printed circuit boards. The unshrouded design allows easy solder termination, facilitating assembly and maintenance.
Operating reliably across a temperature range from -40°C to 105°C, this connector is well-suited for environments found in vehicles, fax machines, printers, PC monitors, and data communication centers.
Features a 2.5 mm pitch for precise PCB compatibility. Includes 13 male contacts arranged in a single row. Constructed with nylon housing and brass contacts with tin plating. Supports a current rating of 3A and voltage up to 250V.
Designed for through hole mounting for reliable mechanical strength. Operates between -40°C to 105°C for robust performance. Unshrouded design facilitates easy solder termination. Suitable for wire-to-board connector systems in various electronic applications.
Applications include automotive, office equipment, data communication, and consumer electronics.
This Molex pin header is part of the Mini-Latch system, providing secure mating connections through a friction locking ramp mechanism. Its design flexibility includes vertical mounting and is compatible with Mini-Latch 51191 and KK series 5051 crimp housings.
Explore more PCB Headers and similar components at EnvMart to find the perfect solution for your industrial and electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header features a pitch of 2.5 mm, ensuring precise compatibility with printed circuit boards (PCBs).
This pin header includes 13 male contacts arranged in a single row.
It supports a maximum operating voltage of 250V, making it suitable for various electrical applications.
The connector supports a continuous current rating of up to 3A.
The housing is made of nylon, while the contacts are constructed from brass with tin plating for enhanced conductivity.
This model is designed for through hole mounting, providing reliable mechanical strength on PCBs.
It operates reliably within a temperature range of -40°C to 105°C, suitable for diverse environments.
The pin header features an unshrouded design, which facilitates easy solder termination.
It is suitable for wire-to-board connector systems in automotive, office equipment, data communication, and consumer electronics applications.
This model is part of the Mini-Latch series, providing secure mating connections through a friction locking ramp mechanism.
The orientation of this pin header is straight, allowing for straightforward installation on PCBs.
It uses solder termination, which is common for secure connections in electronic assemblies.
