STMicroelectronics 100 V 160 A Schottky Diode 4-Pin ISOTOP Package STPS160H100TV
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 9.1mm |
| Length | 38.2mm |
| Model | STPS160H100TV |
| Width | 25.5mm |
| Mount Type | Panel |
| Series | STPS160H100TV |
| Maximum Operating Temperature | 150°C |
| Package Type | ISOTOP |
| Minimum Operating Temperature | -55°C |
| Pin Count | 4 |
| Maximum Continuous Forward Current If | 160A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Isolated |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 40μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1kA |
| Maximum Forward Voltage Vf | 680mV |
| - Capacitance | 45 pF |
Key Features
- High continuous forward current rated at 160 A for demanding applications.
- Peak reverse repetitive voltage of 100 V ensuring robust operation.
- Schottky rectifier type with low forward voltage drop of 680 mV.
- Designed with an insulated ISOTOP package for electrical isolation and safety.
- Fast switching with negligible switching losses suitable for high frequency power supplies.
- Capability to handle peak non-repetitive forward surge current of 1 kA.
- Wide operating temperature range from -55°C to 150°C for harsh environments.
- Low leakage current of 40 μA to enhance efficiency.
Product Description
STMicroelectronics STPS160H100TV is a high voltage Schottky barrier diode featuring a 4-pin ISOTOP insulated package. It is rated for a maximum continuous forward current of 160 A and a peak reverse voltage of 100 V, ideal for secondary rectification in switch mode power supplies.
The diode offers a low forward voltage drop of 680 mV which minimizes conduction losses and improves overall efficiency in high frequency power applications. Its insulated ISOTOP packaging provides electrical isolation up to 2500 VRMS and maintains a low capacitance of 45 pF supporting fast switching performance.
Engineered to withstand harsh conditions, the diode operates reliably between -55°C and 150°C and can tolerate a peak non-repetitive forward surge current of up to 1 kA. Its low leakage current of 40 μA further enhances power saving, making it suitable for industrial, power electronics, and automotive systems.
The device's physical size of 38.2 mm length, 25.5 mm width and 9.1 mm height allows compact and efficient installation on panels. The STPS160H100TV diode is constructed to meet high reliability standards without specific certifications and does not conform to automotive standards.
High continuous forward current rated at 160 A for demanding applications. Peak reverse repetitive voltage of 100 V ensuring robust operation. Schottky rectifier type with low forward voltage drop of 680 mV. Insulated ISOTOP package enabling safe electrical isolation.
Negligible switching losses for high frequency power supplies. Withstands peak surge current of 1 kA for transient conditions. Wide operating temperature range from -55°C to 150°C. Low leakage current of 40 μA for efficient operation.
Compact dimensions: 38.2 mm x 25.5 mm x 9.1 mm. 45 pF capacitance suited for fast switching applications.
This diode is ideal for industrial equipment, power supply units, and electronic manufacturing requiring reliable high current rectification. Browse EnvMart's extensive Semiconductor category for diverse STMicroelectronics products and related Schottky Diodes & Rectifiers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating is 160 A, making it suitable for demanding applications.
The peak reverse repetitive voltage is 100 V, which ensures robust operation in various applications.
It has a low forward voltage drop of 680 mV, which helps minimize conduction losses.
The dimensions are 38.2 mm in length, 25.5 mm in width, and 9.1 mm in height.
It operates reliably within a wide temperature range from -55°C to 150°C.
This diode can handle a peak non-repetitive forward surge current of up to 1 kA.
It is designed with an insulated ISOTOP package, which provides electrical isolation.
The leakage current is low, rated at 40 μA, which enhances efficiency.
The diode has a capacitance of 45 pF, suitable for fast switching applications.
This model is designed for panel mounting, facilitating efficient installation.
It is suitable for industrial equipment, power supply units, and electronic manufacturing requiring reliable high current rectification.
The diode configuration is isolated, providing safety and electrical isolation in its applications.
