STMicroelectronics 7 Seven Darlington Array NPN 500 mA 50 V 16-Pin PDIP ULQ2004A
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 5.1mm |
| Length | 20mm |
| Model | ULQ2004A |
| Mount Type | Through Hole |
| Series | ULQ2004 |
| Maximum Operating Temperature | 105°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | ECOPACK, JESD97 |
| Pin Count | 16 |
| Maximum Continuous Collector Current Ic | 500mA |
| Maximum Collector Emitter Voltage Vceo | 50V |
| Number of Elements per Chip | 7 |
| Minimum DC Current Gain hFE | 1000 |
| Transistor Polarity | NPN |
| Maximum Collector Emitter Saturation Voltage VceSAT | 1.6V |
| Automotive Standard | AEC-Q100 |
| STMicroelectronics 7 Seven Darlington array NPN, 500 mA 50 V HFE | 1000, 16-Pin PDIP |
Key Features
- Contains seven Darlington pairs with NPN transistor polarity for efficient switching.
- Maximum continuous collector current of 500 mA ensures high current handling.
- Maximum collector-emitter voltage of 50 V suitable for various industrial applications.
- High minimum DC current gain (hFE) of 1000 enhances amplification performance.
- Integrates suppression diodes for inductive load protection.
- Designed for through-hole mounting with a 16-pin PDIP package type.
- Operating temperature range from -40°C to 105°C supports harsh environments.
- Complies with ECOPACK and JESD97 standards and AEC-Q100 automotive quality standard.
Product Description
STMicroelectronics ULQ2004A is a high-voltage, high-current Darlington transistor array designed for power switching and amplification applications.
This 16-Pin PDIP package contains seven NPN Darlington pairs, each capable of handling a continuous collector current of up to 500 mA and a maximum collector-emitter voltage of 50 V.
The device features a minimum DC current gain (hFE) of 1000 and integral suppression diodes for reliable operation with inductive loads. Its standard logic level input is compatible with TTL and CMOS devices, making it suitable for industrial and automotive electronic systems.
The ULQ2004A supports through-hole mounting and operates reliably in temperatures ranging from -40°C up to 105°C, meeting ECOPACK, JESD97, and AEC-Q100 automotive standards. Contains seven Darlington pairs with NPN transistor polarity for efficient switching.
Maximum continuous collector current of 500 mA ensures high current handling. Maximum collector-emitter voltage of 50 V suitable for various industrial applications. High minimum DC current gain (hFE) of 1000 enhances amplification performance.
Integrates suppression diodes for inductive load protection. Designed for through-hole mounting with a 16-pin PDIP package type. Operating temperature range from -40°C to 105°C supports harsh environments. Complies with ECOPACK and JESD97 standards and AEC-Q100 automotive quality standard.
This transistor array is ideal for industrial controller boards, automotive electronics, power drivers, and general-purpose high current switching applications requiring robust and reliable transistor arrays.
Explore the range of Darlington Transistors at EnvMart for industrial and commercial electronics projects and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous collector current for this model is 500 mA.
The maximum collector-emitter voltage is 50 V, making it suitable for various industrial applications.
It has a minimum DC current gain (hFE) of 1000, which enhances its amplification performance.
The operating temperature range is from -40°C to 105°C, allowing it to function in harsh environments.
This model is designed for through-hole mounting with a 16-pin PDIP package type.
Yes, it integrates suppression diodes for reliable operation with inductive loads.
The dimensions of this model are 20 mm in length and 5.1 mm in height.
It complies with ECOPACK, JESD97 standards, and the AEC-Q100 automotive quality standard.
This model contains seven Darlington pairs with NPN transistor polarity.
It is compatible with standard logic level inputs for TTL and CMOS devices.
This transistor array is suitable for industrial controller boards, automotive electronics, and general-purpose high current switching applications.
The maximum collector-emitter saturation voltage (VceSAT) is 1.6 V.
