HARWIN M20 Series Straight Surface Pin Header, 10 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded M20-8771042

HARWIN M20-8771042 is a high-quality PCB pin header connector with a 2.54 mm pitch and 10 male contacts in a single straight row, designed for surface mount applications. The connector’s nylon thermoplastic housing withstands soldering reflow temperatures, ensuring durability and reliable performance in various industrial and commercial electronics assembly processes.

Constructed with brass contacts plated in gold, this header offers superior electrical conductivity and corrosion resistance. It supports up to 3A current and can operate across a wide temperature range from -40°C to 105°C, making it suitable for diverse environmental conditions.

The unshrouded design allows flexible mating with M20 series sockets and jumpers, enabling easy customization and cutting to size if necessary, thanks to its castellated housing design. The 5.8 mm mating pin length ensures secure connections in board-to-board and wire-to-board configurations.

Applications include embedded PCs, motherboards, consumer electronics, communications equipment, drives and controls, industrial monitoring systems, and personal computing platforms, demonstrating its versatility and industry standard compliance.

The pin header includes 10 gold-plated brass contacts for excellent signal integrity. The 2.54 mm pitch and single-row layout fit common PCB designs. Nylon housing supports high-temperature reflow soldering. Operates reliably at temperatures from -40°C to 105°C.

Supports a maximum current of 3A for typical signal and low power applications. Surface mount, straight orientation allows easy PCB placement. Unshrouded design offers flexible mating options with M20 PCB sockets and jumpers.

This connector is manufactured in Taiwan, Province Of China, and is supplied new to meet industry standard requirements. The HARWIN M20 series ensures flexibility with multiple pin configurations and mating lengths to suit any design.
