HARWIN M20 Series Straight Through Hole Pin Header, 12 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded M20-9980645

HARWIN M20-9980645 is a high-quality straight through hole pin header connector from the M20 series, featuring 12 contacts arranged in a 2-row configuration with a 2.54 mm pitch. This unshrouded male connector is designed for through hole mounting applications on printed circuit boards, offering excellent electrical performance and mechanical robustness.

The housing is made of durable nylon material capable of withstanding high temperatures typical of reflow soldering processes. The contacts are brass with gold plating, providing corrosion resistance and dependable conductivity. With a tail pin length of 3 mm and mating pin length of 6.1 mm, it ensures a secure and precise connection in board-to-board and wire-to-board systems.

Operating in a temperature range of -40°C to 105°C, it is engineered to perform reliably in demanding industrial and electronic environments. This pin header is ideal for use in embedded PCs, motherboards, consumer electronics, communication devices, drives and controls, and industrial monitoring equipment.

The M20 series offers multiple configuration options and different pin mating lengths, allowing designers flexibility in their circuit board layouts. The castellated housing design allows for cutting to size, facilitating custom fitment while maintaining connection integrity.

Manufactured with nylon housing providing high temperature resistance. Two-row, unshrouded configuration for versatile PCB mounting. Contacts made of brass with gold plating ensure durability and conductivity. Designed for through-hole mount with male contact gender.

Operates between -40°C to 105°C for stable performance. Tail pin length of 3 mm and mating pin length of 6.1 mm for secure connection. Suitable for embedded PCs, motherboards, and large electronics systems. Compatible with M20 series PCB sockets, socket housings, and jumpers.

Thermoplastic housing withstands reflow soldering processes.

Available with multiple pin lengths and configurations, the HARWIN M20 series pin headers provide an adaptable solution for a wide range of electronic assembly applications, ensuring quality and consistency. Explore the full range of HARWIN PCB connectors and headers on EnvMart for trusted industrial and commercial electronic component needs.
