HARWIN Archer M50 Series Straight Surface Pin Header, 20 Contacts, 1.27 mm Pitch, 2 Row, Unshrouded M50-3601042

HARWIN M50-3601042 Archer M50 Series pin header is a high-quality, industry-standard connector designed for board-to-board and wire-to-board applications. Featuring 20 male contacts spaced at 1.27 mm pitch in two rows, this straight, unshrouded surface mount header provides robust mechanical and electrical connection with excellent durability offered by the liquid crystal polymer housing. The gold plating on copper alloy contacts ensures minimal contact resistance and corrosion resistance to maintain signal integrity over time.

This connector supports a current rating of 1 ampere and operates reliably in temperature ranges from -40°C to 105°C. The pin lengths are optimized with a mating length of 3 mm and tail pin length of 2.3 mm to facilitate secure soldering and mechanical stability. Its compact design and compatibility with the Archer M50 series add flexibility for custom PCB configurations, including cutting to size for varying pin counts.

The non-shrouded design allows easy access to contacts, suitable for applications requiring rapid assembly or maintenance. Typical industrial use cases include electronic equipment, navigation systems, automotive control modules, communications equipment including telecom and datacom systems, medical diagnostic instruments such as X-Ray machines, and industrial test and monitoring systems.

Available with surface mount technology (SMT) mounting type, this component enhances space efficiency on PCBs and delivers reliable performance in demanding industrial and commercial environments. The product is manufactured to meet stringent quality standards, ensuring long-term durability and excellent electrical performance for industrial, laboratory, electronics manufacturing, and HVAC industries.

Model M50-3601042 with 20 male contacts arranged in 2 rows. Housing constructed from durable liquid crystal polymer. Gold-plated copper alloy contacts for reliable electrical performance. Designed for solder termination on surface mount PCBs.

Supports a maximum current of 1 ampere at temperatures up to 105 degrees Celsius. Operating temperature range from -40°C to 105°C ensures robustness in diverse environments. Mating pin length of 3 mm with tail pin length of 2.3 mm.

Non-shrouded design allows for flexible connection options. Compatible with Archer M50 series connectors for easy integration. Explore the extensive range of connectors and electronics components at EnvMart for seamless electronic design and manufacturing solutions.
