TE Connectivity AMP-LATCH Series Right Angle Through Hole PCB Header, 10 Contact 2.54 mm Pitch 2 Row Shrouded 2-1761609-3
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | AMP-LATCH |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a 2.54 mm pitch for precise wire-to-board connections.
- Includes 10 gold-plated phosphor bronze contacts for optimal conductivity.
- Constructed with durable polybutylene terephthalate housing for stability.
- Designed with a right angle orientation and shrouded connector system.
- Supports a maximum operating voltage of 250V and current of 1A.
- Operates reliably between -65°C and 105°C temperature range.
- Utilizes solder termination type for secure PCB mounting.
- Offers military and center polarization with ejector latches for secure mating and easy removal.
Product Description
TE Connectivity 2-1761609-3 AMP-LATCH Series Right Angle Through Hole PCB Header is engineered for robust and secure wire-to-board connections with 10 male contacts arranged in a shrouded, 2-row configuration with 2.54 mm pitch.
The header housing is made from polybutylene terephthalate providing excellent mechanical durability. The phosphor bronze contacts are gold-plated ensuring high conductivity and corrosion resistance. Designed for solder termination and through-hole mounting, this PCB header is optimized for industrial, medical, networking, and commercial electronics applications.
Its right angle orientation and military-grade center polarization features enhance compatibility and assembly ease. Ejector latches enable secure connection with easy disconnection from mating IDC ribbon cable receptacles. Options for long or short latch styles allow tailoring to specific strain relief requirements.
Rated for 250V voltage and 1A current with an operating temperature range from -65°C to 105°C, this product excels in demanding environments typical in industrial controls and electrical testing equipment.
Features a 2.54 mm pitch for precise wire-to-board connections. Includes 10 gold-plated phosphor bronze contacts for optimal conductivity. Constructed with durable polybutylene terephthalate housing for stability. Designed with a right angle orientation and shrouded connector system.
Supports a maximum operating voltage of 250V and current of 1A. Operates reliably between -65°C and 105°C temperature range. Utilizes solder termination type for secure PCB mounting. Offers military and center polarization with ejector latches for secure mating and easy removal.
Suitable for applications in PCs, medical equipment, networking, industrial controls, and electrical testing.
This PCB header is ideal for use in electronic manufacturing, industrial automation, and commercial product assemblies where secure connectors with reliable electrical performance are critical.
Explore our range of PCB Headers for diverse industrial and commercial electronic applications at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a maximum operating voltage of 250V and a current of 1A.
The contacts in this model are arranged with a 2.54 mm pitch.
The contacts are made of phosphor bronze and are gold-plated for optimal conductivity, while the housing is constructed from polybutylene terephthalate.
It operates reliably between -65°C and 105°C.
This model features 10 male contacts.
It utilizes a solder termination type for secure PCB mounting.
The connector is designed with a right angle orientation.
This model is a shrouded connector, enhancing its compatibility and assembly ease.
It is suitable for applications in PCs, medical equipment, networking, industrial controls, and electrical testing.
It features military-grade center polarization and ejector latches for secure mating and easy removal.
The country of origin for this PCB header is India.
This PCB header is designed for through-hole mounting.
