Amphenol Communications Solutions Minitek Series Straight Surface PCB Socket 12-Contact 1 Row 2 mm Pitch 10131935-112ULF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 200V |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Current | 12A |
| Model | 10131935-112ULF |
| Mount Type | Surface |
| Housing Material | Glass Filled |
| Contact Material | Copper |
| Series | Minitek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Receptacle |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Compact 2.00 mm pitch reduces PCB space usage by 38 percent.
- Designed for board-to-board and wire-to-board applications with 12 contacts in a single row.
- Dual beam contact design ensures reliable electrical performance with 12A current rating.
- Surface-mount housing made of high-temperature UL94V-0 thermoplastic.
- Gold-plated copper female contacts provide excellent conductivity and corrosion resistance.
- Operating temperature range from -55°C to 125°C for versatile environments.
- Double solder tail facilitates automated assembly without orientation constraints.
- Suitable for automotive, I/O modules, server drives, and PLC applications.
Product Description
Amphenol Communications Solutions 10131935-112ULF Minitek Series Straight Surface PCB Socket is a high-quality, 12-contact receptacle connector designed for board-to-board and wire-to-board electronic applications. Featuring a 2.00 mm pitch, this PCB socket occupies 38% less board space compared to standard 2.54 mm connectors, making it ideal for compact designs.
The single-row configuration with female copper contacts is gold plated for enhanced conductivity and corrosion resistance. Its dual beam contact design ensures reliable electrical performance, supporting a current of up to 12A when multiple contacts are powered.
The socket housing is manufactured from glass-filled, UL94V-0 thermoplastic, providing excellent heat resistance necessary for reflow soldering processes. Its surface mount type and straight orientation facilitate easy integration on PCB assemblies. With an operating temperature range from -55°C to 125°C, this connector is suitable for demanding industrial and automotive environments.
Additional features include a double solder tail per contact for automatic placement on assembly lines, ensuring efficiency and reliability. The Minitek series offers a modular system with various configurations to match diverse design needs, perfectly mating with Minitek 2.0 mm headers for flexible electronic interconnect solutions.
Compact 2.00 mm pitch reduces PCB space requirements by 38%. 12-contact single-row female receptacle configuration. Gold-plated copper contacts ensure high conductivity and durability. Glass-filled UL94V-0 thermoplastic housing withstands high temperatures.
Operates reliably between -55°C and 125°C. Supports 12A current with multiple contacts powered. Surface mount housing for automated PCB assembly. Double solder tail design supports automated manufacturing processes. Compatible with Minitek 2.0 mm modular connector system.
This PCB socket is ideal for use in automotive, industrial, and server equipment, including I/O modules and programmable logic controllers (PLCs). Its robust design ensures consistent performance in critical electronic applications. Browse EnvMart for more connectors and PCB socket solutions from leading brands.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB socket is 2.00 mm, which reduces PCB space usage by 38% compared to standard 2.54 mm connectors.
This model features 12 contacts in a single-row configuration.
The maximum current rating for this socket is 12A when multiple contacts are powered.
The housing is made from glass-filled UL94V-0 thermoplastic, and the contacts are gold-plated copper, providing excellent conductivity and corrosion resistance.
It operates reliably within a temperature range of -55°C to 125°C.
This model uses surface mount technology, facilitating easy integration on PCB assemblies.
Yes, it is compatible with the Minitek 2.0 mm modular connector system, allowing for flexible electronic interconnect solutions.
The orientation of this socket is straight, which aids in its integration into various designs.
This socket utilizes a solder termination type.
It is suitable for automotive, I/O modules, server drives, and PLC applications.
The voltage rating for this socket is 200V.
The country of origin for this PCB socket is India.
