ASSMANN WSW 9-Way IDC Connector Male for Cable, 2 Row, 250V AC, 1A A-DSF 09LPIII/Z-UNC

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW 9-Way IDC Connector Male for Cable, 2 Row, 250V AC, 1A A-DSF 09LPIII/Z-UNC

Name: ASSMANN WSW 9-Way IDC Connector Male for Cable, 2 Row, 250V AC, 1A A-DSF 09LPIII/Z-UNC
Brand: ASSMANN WSW
SKU: 208262
Price: 1.82 USD
Availability: InStock



Category IDC Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Brand	ASSMANN WSW
Orientation	Straight
Current	1A
Model	A-DSF 09LPIII/Z-UNC
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	AD
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold, Nickel, Tin
Number of Contacts	9
Contact Gender	Male
Connector Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

Supports a current rating of 1 ampere at 250 volts AC.
Features a 2.54 mm pitch between contacts for standard interfacing.
Constructed with brass contacts plated in gold, nickel, and tin for reliable connectivity.
Uses a shrouded male connector design ensuring secure cable orientation and connection.
Designed with a polybutylene terephthalate housing for durability and insulation.
Operates reliably between -55°C to 105°C temperature range.
Termination via Insulation Displacement Contact (IDC) technology allows efficient assembly.
Ideal for industrial, electronic, and power connector applications requiring high performance.

Product Description

ASSMANN WSW A-DSF 09LPIII/Z-UNC 9-Way IDC Connector Male for Cable, featuring 2 rows of contacts, designed for reliable signal and power transmission. This connector supports up to 1A current at 250V AC, making it suitable for a variety of industrial and electronic applications including power connectors and PCB interfacing. Its 2.54 mm pitch and shrouded male contact design provide secure, stable connections while preventing misalignment.

The connector's metallic contacts are made of brass with a gold, nickel, and tin plating combination, ensuring corrosion resistance and enhanced conductivity. The housing is made from robust polybutylene terephthalate material offering excellent durability and insulation. It employs IDC termination technology allowing cable wires to be inserted without soldering, speeding assembly and improving production efficiency.

Engineered to withstand operating temperatures from -55°C to 105°C, this connector is highly versatile for use in harsh environmental conditions. Its straight orientation and cable mount type make it suitable for many wiring harnesses and manufacturing setups.

Supports 9 contacts arranged in 2 rows for dense wiring solutions. Rated for 1 amp current and 250V AC voltage handling. Gold, nickel, and tin plated brass contacts for conductivity and durability. Polybutylene terephthalate housing ensures mechanical strength and insulation.

Termination via IDC for quick, reliable cable connection without solder. Operation temperature range from -55°C to 105°C ensures reliability. Shrouded male connector design enhances safety and connection integrity.

This product is widely applicable across electronic component assemblies, power distribution setups, industrial equipment wiring, and manufacturing environments requiring robust and reliable cable connectors. Choosing ASSMANN WSW connectors guarantees quality and longevity for professional-grade installations.
